Gigabyte GA-AB350M-D3V (rev. 1.x) [4/39] Box contents

- 4 -

GA-AB350M-D3V Motherboard Layout

* The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.

Box Contents

5 GA-AB350M-D3V motherboard

5 Motherboard driver disk 5 Two SATA cables

5 User's Manual 5 I/O Shield

KB_MS_USB

VGADVI

R_USB30

USB31_LAN

Socket AM4

ATX

AUDIO

DDR4_1

DDR4_2

ATX_12V

AMD B350

M_BIOS

PCIEX1_2

PCIEX16

PCIEX1_1

CODEC

GA-AB350M-D3V

F_USB1

CLR_CMOS

F_USB2TPMCOMF_AUDIO

SPDIF_O

F_USB30F_PANEL

SYS_FAN1

CPU_FAN

iTE

Super I/O

BAT

Realtek

GbE LAN

SPEAKER

SATA3

M2F_32G

426080110
