Installation manual
16
EWAQ+EWYQ005~007AAV3P
Packaged air-cooled water chillers and
packaged reversible air to water heat pumps
4PW27339-1D
TECHNICAL SPECIFICATIONS
General
Electrical specifications
Cooling only models Heat pump models
EWAQ005AAV3P EWAQ006AAV3P EWAQ007AAV3P EWYQ005AAV3P EWYQ006AAV3P EWYQ007AAV3P
Nominal capacity
• cooling 5.2 kW 6.0 kW 7.1 kW 5.2 kW 6.0 kW 7.1 kW
• heating ———6.1 kW 6.8 kW 8.2 kW
Dimensions H x W x D 805 x 1190 x 360 mm
Weight
• machine weight 100 kg
• operation weight 104 kg
Connections
•water inlet/outlet 1” MBSP
(*)
•water drain hose nipple 1/2” FBSP
(**)
Refrigerant
•Type R410 A
• Charge 1.7 kg
Expansion vessel
•Volume 6 l
• Pre-pressure 1 bar
• Maximum working pressure (MWP) 3.0 bar
Pump
•Type water cooled
•no. of speed 3
• Nominal ESP normal: 25 kPa, high: 40 kPa
Sound level
• Sound power 63 dBA 64 dBA 66 dBA 63 dBA 64 dBA 66 dBA
• Sound pressure (at 1 m distance) 47 dBA 49 dBA 53 dBA 47 dBA 49 dBA 53 dBA
Internal water volume 4 l
Nominal water flow 14.3 l/min 17.2 l/min 20.4 l/min 14.3 l/min 17.2 l/min 20.4 l/min
Pressure relief valve water circuit 3 bar
Operation range - water side
• heating — +30 ~ +55°C
• cooling +7 ~ +20°C +7 ~ +20°C
Operation range - air side
• heating — -15 ~ +25°C
• cooling +15 ~ +43°C +15 ~ +43°C
(*) MBSP = Male British Standard Pipe
(**) FBSP = Female British Standard Pipe
Cooling only models Heat pump models
EWAQ005AAV3P EWAQ006AAV3P EWAQ007AAV3P EWYQ005AAV3P EWYQ006AAV3P EWYQ007AAV3P
Power circuit
• Phase 1P
•Frequency 50 Hz
•Voltage 230 V
• Maximum running current 17.3 A 19 A
