150WSingleOutputwithPFCFunction

ASP-150 series

Universal AC input / Full range

Built-in active PFC function, PF>0.95

Protections: Short circuit / Overload / Over voltage / Over temperature

Cooling by free air convection

High power density 8.4w/in

100% full load burn-in test

No load power consumption<1W@240VAC

ZCS/ZVS technology to reduce power dissipation

3 years warranty

Features :

SPECIFICATION

OVERTEMPERATURE

90 10 (RTH2)detectonheatsinkofpowertransistor

Protectiontype:Shutdowno/pvoltage,re-powerontorecover

Fixed.Canbemodifiedbetweentherangeabovebyfactory

ASP-150-12 ASP-150-15 ASP-150-20 ASP-150-24 ASP-150-48

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

OUTPUT VOLTAGE ADJ.RANGE

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

POWERFACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

WORKINGHUMIDITY

WORKINGTEMP.

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVERVOLTAGE

ACCURRENT (Typ.)

12V 15V 20V 24V 48V

11A 9.5A 7.5A 6.3A

0~6.3A

151.2W

3.2A

0~11A 0~9.5A 0~7.5A 0~3.2A

132W 142.5W 150W 153.6W

150mVp-p 180mVp-p 200mVp-p 240mVp-p 240mVp-p

11~13.2V 14~17V 17~22V 22~27V 45.6~52.8V

2.0% 2.0% 1.0% 1.0% 1.0%

0.5% 0.5% 0.5%

0.5%1.0%

0.5% 0.5%

0.5%1.0% 0.5%

3000ms,80msatfullload

50ms/230VAC 16ms/115VACatfullload

90~264VAC127~370VDC

47~63Hz

PF 0.95/230VACPF 0.98/115VAC

atfullload

88% 88% 90%

17.5~20.25V 22.5~28V

90%

27.5~32.4V

89%

53.3~64.8V

2A/115VAC1A/230VAC

COLDSTART 80A/230VAC

<2mA /240VAC

105~135% ratedoutputpower

13.7~16.2V

Protectiontype:Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

Protectiontype:Shutdowno/pvoltage,re-powerontorecover

20~90%RHnon-condensing

-20~+60

(Referto"DeratingCurve")

-20~+85 ,10~95%RH

0.05%/ (0~50

10~500Hz,2G10min./1cycle,periodfor60min. eachalongX, Y,Zaxes

149.3Khrsmin.MIL-HDBK-217F(25 )

169*60.7*28.5mm(L*W*H)

0.32Kg;48pcs/15.8Kg/0.79CUFT

SAFETY STANDARDS

UL60950-1,CB(IEC60950-1)approved

CompliancetoEN55022(CISPR22) ,ClassB EN61000-3-2,-3

CompliancetoEN61000-4-2,3,4,5,6,8,11,lightindustrylevel,criteria A

ENVIRONMENT

SAFETY &

EMC

(Note4)

PROTECTION

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:4.25KVDCI/P-FG:1.5KVACO/P-FG:0.5KVAC

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC /25 /70%RH

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Heat Sink HS1,HS3 & HS2,HS3 can not be shorted.

For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

(as available on http://www.meanwell.com)

FileName:ASP-150-SPEC2011-06-16

EMCIMMUNITY

EMCEMISSION
