BlockDiagram
MechanicalSpecification
DeratingCurve OutputDeratingVSInputVoltage
FileName:ASP-150-SPEC2011-06-16
Unit:mm
AMBIENTTEMPERATURE( )
INPUTVOLTAGE(V)60Hz
90 100 110 135 155 230 264
100
90
80
70
60
50
40
LOAD(%)
LOAD(%)
-20 0 10 20 30 40 50 60 70
20
40
60
80
100
DETECTION
PWM
CIRCUIT
O.L.P.
EMIFILTER
RECTIFIERS
CIRCUIT
CONTROL
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
PFC
PFC
ACInputConnector(CN1):JST B5P-VHorequivalent
PinNo.
1
3
5
2,4
Assignment
AC/L
AC/N
FG
NoPin
MatingHousing
JST VHR JST SVH-21T-P1.1
orequivalent orequivalent
Terminal
DCOutputConnector(CN2):JST B6P-VHorequivalent
PinNo.
1,2,3
4,5,6
Assignment
-V
+V
MatingHousing
JST VHR
orequivalent
Terminal
JST SVH-21T-P1.1
orequivalent
LED
FS1
160.5
169
3.5
60.7
50.7
28.5max.
5
CN1
1
2
4
3
5
CN2
4- 3.3
5
3
4
2
1
6
(HORIZONTAL)
T4A/250V
ACFUSE
HS1
HS2
HS3
HS1,HS3&HS2,HS3cannotbeshorted
150WSingleOutputwithPFCFunction
ASP-150 series
