SPECIFICATION

MPS-30-5 MPS-30-12 MPS-30-15 MPS-30-24 MPS-30-27 MPS-30-48

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

OUTPUT

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

EFFICIENCY (Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

WORKINGTEMP.

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVERVOLTAGE

OVERTEMPERATURE

ACCURRENT (Typ.)

5V 12V 15V 24V 27V 48V

5A 2.5A 2A 1.2A 1.1A 0.6A

0~5A 0~2.5A 0~2A

0~1.2A

0~1.1A 0~0.6A

25W 30W 30W 28.8W 29.7W 28.8W

80mVp-p 120mVp-p 150mVp-p 240mVp-p 240mVp-p 240mVp-p

3.0% 3.0% 3.0% 3.0% 3.0% 2.0%

1.0% 1.0% 0.5% 0.5% 0.5% 0.5%

2.0% 1.0% 1.0% 1.0% 1.0% 1.0%

88~264VACautoswitch120~370VDC

47~63Hz

72% 75% 76% 77% 78% 78%

0.8A/115VAC0.5A/230VAC

COLDSTART 30A/230VAC

Above105% ratedoutputpower

5.5~6.75V

Tj135 typically(U1)detectonmaincontrolIC

13.2~16.2V 16.5~20.25V 26.4~32.4V 29.7~36.45V 52.8~64.8V

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

Protectiontype: Shutdowno/pvoltage,re-powerontorecover

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

-20~+85 ,10~95%RH

0.03%/ (0~50

10~500Hz,2G10min./1cycle,periodfor60min. eachalongX, Y,Zaxes

547Khrsmin.MIL-HDBK-217F(25 )

101.6*65.8*23.5mm(L*W*H)

0.16Kg;90pcs/15.8Kg/1.02CUFT

FileName:MPS-30-SPEC2012-05-22

500ms,30ms/230VAC500ms,30ms/115VACatfullload

70ms/230VAC12ms/115VACatfullload

-10~+60 (Referto"DeratingCurve")

20~90%RH non-condensing

SAFETY STANDARDS

ANSI/AAMIES60601-1, TUVEN60601-1,IEC60601-1approved

CompliancetoEN55011(CISPR11)ClassB, EN61000-3-2,-3

Complianceto EN61000-4-2,3,4,5,6,8,11,EN55024,EN60601-1-2,medicallevel,criteria A

30WSingleOutputforMedical Type

MPS-30 series

Universal AC input / Full range

Low leakage current <200 A

Protections: Short circuit / Overload / Over voltage / Over temperature

Fixed switching frequency at 100KHz

Low cost

High reliability

3 years warranty

Features :

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:4KVACI/P-FG: O/P-FG:SHORT2KVAC

I/P-O/P,I/P-FG:100MOhms/500VDC /25 /70%RH

ENVIRONMENT

SAFETY &

EMC

(Note4)

PROTECTION

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

(as available on http://www.meanwell.com)

EMCIMMUNITY

EMCEMISSION

Earthleakagecurrent<200 A/264VAC
