SPECIFICATION

PD-25A PD-25B PD-2505 PD-2512 PD-2515

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

OUTPUT

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

EFFICIENCY(Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

SAFETY STANDARDS

WORKINGTEMP.

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVERVOLTAGE

ACCURRENT (Typ.)

5V 5V 5V 12V 15V

2.1A 1.2A 2.5A 1A 0.8A

0.2~2.5A 0.2~2A 0.1~3A 0.1~1.2A 0.1~1A

25W 25.2W 25W 24W 24W

50mVp-p 50mVp-p 50mVp-p 50mVp-p 50mVp-p

2.0% 2.0% 4.0% 4.0% 4.0% 4.0%6.0% 6.0% 6.0%6.0%

0.5% 0.5% 0.5% 0.5% 0.5% 0.5%2.0% 2.0% 1.0%1.0%

1.0% 1.0% 3.0% 3.0% 3.0% 3.0%4.0% 4.0% 4.0%4.0%

250ms,50ms/230VAC250ms,30ms/115VACatfullload

100ms/230VAC16ms/115VACatfullload

85~264VAC120~370VDC

47~63Hz

71% 77% 73% 74% 75%

0.65A/115VAC0.4A/230VAC

COLDSTART 32A

<0.5mA /240VAC

Above105% ratedoutputpower

5.75~6.75V 13.8~16.2V 5.75~6.75V 27.6~32.4V 5.75~6.75V 13.8~16.2V-5.75~-6.75V -13.8~-16.2V 17.3~20.3V -17.3~-20.3V

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

Protectiontype: Shutoffo/pvoltage,clampingbyzenerdiode

Protectiontype:Shutdowno/pvoltage,re-powerontorecover

UL60950-1, TUVEN60950-1approved

-10~+60 (Refertooutputloadderatingcurve)

20~90%RHnon-condensing

-20~+85 ,10~95%RH

0.03%/ (0~50 )ONCH1output

10~500Hz,2G10min./1cycle,periodfor60min. eachalongX, Y,Zaxes

507.9Khrsmin.MIL-HDBK-217F(25 )

107*61*28mm(L*W*H)

0.15Kg;96pcs/15.9Kg/1.3CUFT

FileName:PD-25-SPEC2008-03-25

1.2A 0.8A 2.5A 1A 0.8A

0.1~1.5A 0.1~1A 0.1~2.5A 0.1~1.2A 0.1~1A

150mVp-p 200mVp-p 50mVp-p 50mVp-p 50mVp-p

12V

CH2 CH2 CH2 CH2 CH2

24V -5V -12V -15V

OVERTEMPERATURE

HARMONICCURRENT

EMSIMMUNITY

CompliancetoEN55022(CISPR22)ClassB

Complianceto EN61000-3-2,-3

CompliancetoEN61000-4-2,3,4,5,lightindustrylevel,criteria A

25WDualOutputSwitchingPowerSupply

PD-25 series

Features :

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

EMICONDUCTION&RADIATION

ENVIRONMENT

SAFETY &

EMC

(Note4)

PROTECTION

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

Tj135 typically(U1)detectonmaincontrolIC

Universal AC input / Full range

Low leakage current<0.5mA

Protections: Short circuit / Overload / Over voltage / Over temperature

Cooling by free air convection

100% full load burn-in test

Fixed switching frequency at 100KHz

Low cost

High reliability

2 years warranty

CH1 CH1 CH1 CH1 CH1

OUTPUTNUMBER
