CH1

SPECIFICATION

PD-65A

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

OUTPUT

VOLTAGE ADJ.RANGE

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

EFFICIENCY(Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

WORKINGTEMP.

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

ACCURRENT (Typ.)

5V 12V

CH2

5.5A 2.8A

0.4~7A 0.2~3.2A

61.1W

Ratedoutputpowerforconvection;72Wwith18CFMmin.Forcedair

50mVp-p 120mVp-p

CH1:4.75~5.5V

4.0% 7.0%

1.0% 2.0%

3.0% 4.0%

800ms,20msatfullload

60msatfullload

90~264VAC127~370VDC

47~440Hz

78%

1.5A/115VAC0.9A/230VAC

COLDSTART 20A/115VAC40A/230VAC

<0.75mA

73~105W ratedoutputpower

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved.

-10~+60 (Refertooutputloadderatingcurve)

20~90%RHnon-condensing

-20~+85 ,10~95%RH

0.04%/ (0~50 )on+5Voutput

10~500Hz,2G10min./1cycle,Periodfor60min.eachalongX, Y,Zaxes

288.1Khrsmin.MIL-HDBK-217F(25 )

127*76*42mm(L*W*H)

0.24Kg;54pcs/15Kg/1.35CUFT

FileName:PD-65-SPEC 2007-03-14

CH1:5.75~6.75VDConCH1

OVERVOLTAGE

SAFETY STANDARDS

HARMONICCURRENT

EMSIMMUNITY

Complianceto EN55022(CISPR22)ClassB

Complianceto EN61000-3-2,-3

Complianceto EN55024,Lightindustrylevel,criteria AEN61000-4-2,3,4,5,6,8,11;ENV50204,

Features :

PD-65 se ri es

ENVIRONMENT

SAFETY &

EMC

(Note4)

PROTECTION

EMICONDUCTION&RADIATION

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Mounting holes M1 and M2 should be grounded for EMI purposes.

Universal AC input / Full range

Low leakage current<0.5mA

Protections: Short circuit / Overload / Over voltage

Cooling by free air convection

100% full load burn-in test

Fixed switching frequency at 65KHz

2 years warranty

OUTPUTPOWER(max.)

UL60950-1, TUVEN60950-1 Approved

CH1

OUTPUTNUMBER

PD-65B

24V

CH2

3.5A 2A

0.4~6A 0.2~2.6A

65.5W

150mVp-p50mVp-p

CH1:4.75~5.5V

7.0%4.0%

2.0%1.0%

4.0%3.0%

81%

65WDualOutputSwitchingPowerSupply
