FileName:PD-65-SPEC 2007-03-14
Unit:mm
fosc:65KHz
DCOutputConnector(CN2):Molex5273-06orequivalent
PinNo.
1
2,3
4,5
6
Assignment
+V
+5V
COM
NC
MatingHousing
Molex5195
orequivalent
Terminal
Molex5194
orequivalent
ACInputConnector(CN1):Molex5277-02orequivalent
PinNo.
1
2
Assignment MatingHousing
Molex5195
Molex5194
orequivalent
orequivalent
Terminal
LOAD(%)
BlockDiagram
MechanicalSpecification
AMBIENTTEMPERATURE( )
(HORIZONTAL)
-10 0 10 20 30 40 50 60
20
40
60
80
100
O.V.P.
CONTROL
ING
COM
+5V
RECTIFIERS
&
FILTER
SWITCH-
POWER
FILTER
&
RECTIFIERS
O.L.P.
DETECTION
CIRCUIT
PWM
FILTER
&
RECTIFIERS
+V
FG
I/P
FILTER
EMI
65WDualOutputSwitchingPowerSupply
SVR1
115.8
5.6
76
64.8
42
127
FG
4
6
5
2
3
CN2
4- 3.8
1
5.6
M1 M2
2
1
CN1
ACFUSE
F4A/250V
90 100 110 135 155 264230
100
90
80
70
60
50
40
INPUTVOLTAGE(V)60Hz
LOAD(%)
OutputDeratingVSInputVoltageDeratingCurve
AC/N
AC/L
PD-65 series
