SPECIFICATION

PPS-125-3.3 PPS-125-5 PPS-125-12 PPS-125-13.5 PPS-125-15 PPS-125-24 PPS-125-27 PPS-125-48

MODEL

DCVOLTAGE

RATEDCURRENT

RATEDPOWER(convection)

RATEDPOWER (18CFMFAN)

OUTPUT

VOLTAGE ADJ.RANGE

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

POWERFACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

SAFETY STANDARDS

WORKINGTEMP.

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

PACKING

OVERLOAD

OVERVOLTAGE

ACCURRENT

(Typ.)

3.3V 5V 12V 13.5V 15V 24V 27V 48V

20A 20A 8.5A 7.5A 6.7A 4.2A 3.8A 2.1A

0~20A

0~25A

0~20A

0~25A

0~8.5A

0~10.5A

0~7.5A

0~9.3A

0~6.7A

0~8.4A

0~4.2A

0~5.2A

0~3.8A

0~4.6A

0~2.1A

0~2.6A

66W

82.5W

100W

125W

102W

126W

101.25W

125.55W

100.5W

126W

100.8W

124.8W

102.6W

124.2W

100.8W

124.8W

100mVp-p 100mVp-p 100mVp-p 100mVp-p 100mVp-p 150mVp-p 150mVp-p 250mVp-p

3.13~3.46V 4.75~5.25V 11.40~12.60V 12.82~14.17V 14.25~15.75V 22.80~25.20V 25.65~28.35V 45.60~50.40V

2.0% 2.0% 2.0% 2.0% 2.0% 1.0% 1.0% 1.0%

0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5%

1.0% 1.0% 1.0% 1.0% 1.0% 1.0% 1.0% 1.0%

1000ms,30ms/230VAC2000ms,30ms/115VACatfullload

24ms/230VAC24ms/115VACatfullload

90~264VAC127~370VDC

47~63Hz

PF>0.93/230VACPF>0.98/115VACatfullload

70% 79% 80% 80% 80% 83% 83% 84%

1.2A115VAC

230VAC 0.6A

COLDSTART 24A/230VAC

<2mA /240VAC

130~160% ratedoutputpower

3.63~4.45V 5.5~6.75V 13.8~16.2V 15.5~20.25V 17.25~20.25V 27.6~32.4V 31.05~36.45V 57.6~67.2V

Protectiontype:Foldbackcurrentlimiting,recoversautomaticallyafterfaultconditionisremoved

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

UL60950-1, TUVEN60950-1approved

CompliancetoEN55022(CISPR22)ClassB, EN61000-3-2,-3

CompliancetoEN61000-4-2,3,4,5,6,8,11,EN55024,lightindustrylevel,criteria A

-20~+70

(Referto"DeratingCurve")

20~90%RHnon-condensing

-40~+85 ,10~95%RH

0.05%/ (0~50

10~500Hz,2G10min./1cycle,60min.eachalongX, Y,Zaxes

111.7Khrsmin.MIL-HDBK-217F(25 )

127*76.2*34.6mm(L*W*H)

0.37Kg; 36pcs/14.3Kg/0.79CUFT

1.7A

0.75A

FileName:PPS-125-SPEC2011-08-18

125WSingleOutputwithPFCFunction

PPS-125 se ri es

Universal AC input / Full range

Built-in active PFC function

Protections: Short circuit / Overload / Over voltage

PWM control and regulated

High power density 6.117W/inch

Built-in remote sense function

LED indicator for power on

100% full load burn-in test

125W with 18CFM FAN

5"x3" compact size

3 years warranty

Features :

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC /25 /70%RH

SAFETY &

EMC

(Note4)

PROTECTION

ENVIRONMENT

CURRENTRANGE(convection)

CURRENTRANGE(18CFMFAN)

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

NOTE

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Heat Sink HS1,HS2 & HS3 can not be shorted.

For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

(as available on http://www.meanwell.com)

EMCIMMUNITY

EMCEMISSION
