SPECIFICATION

PPS-200-5 PPS-200-12 PPS-200-15 PPS-200-24 PPS-200-27 PPS-200-48

MODEL

DCVOLTAGE

RATEDCURRENT

RATEDPOWER(convection)

RATEDPOWER (20.5CFMFAN)

OUTPUT

VOLTAGE ADJ.RANGE

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

POWERFACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

SAFETY STANDARDS

WORKINGTEMP.

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

PACKING

OVERLOAD

OVERVOLTAGE

OVERTEMPERATURE

ACCURRENT (Typ.)

5V 12V 15V 24V 27V 48V

36A 16.6A 13.3A 8.3A 7.4A 4.167A

0~26A

0~36A

0~12.5A

0~16.6A

0~10A

0~13.3A

0~6.25A 0~5.56A 0~3.13A

0~8.3A 0~7.4A 0~4.167A

130W

180W

150W

199.2W

150W

199.5W

150W 150W 150.24W

199.2W 199.8W 200.016W

100mVp-p 100mVp-p 100mVp-p 150mVp-p 150mVp-p 250mVp-p

4.5~5.5V 10.8~13.2V 13.5~16.5V 21.6~26.4V 24.3~30V 43.2~52.8V

4.0% 3.0% 3.0% 2.0% 2.0% 2.0%

0.5% 0.5% 0.5% 0.5% 0.5% 0.5%

1.0% 1.0% 1.0% 1.0% 1.0% 1.0%

1200ms,60ms/230VAC2500ms,60ms/115VACatfullload

90~264VAC127~370VDC

11ms/230VAC/115VACatfullload

47~63Hz

PF>0.93/230VACPF>0.98/115VACatfullload

86% 89% 89% 89% 89% 90%

2.2A/115VAC1.2A/230VAC

COLDSTART 70A/230VAC

<2mA /240VAC

105~135% ratedoutputpower

5.6~7.25V

110 5

( )dTSW1 etectonheatsinkofpowertransistor

13.8~16.2V 17.25~20.25V 27.6~32.4V 31.05~36.45V 57.6~67.2V

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

Protectiontype: Shutdowno/pvoltage,recoversautomaticallyaftertemperaturegoesdown

UL60950-1, TUVEN60950-1approved

CompliancetoEN55022(CISPR22) ,ClassB EN61000-3-2,-3

CompliancetoEN61000-4-2,3,4,5,6,8,11,EN55024,lightindustrylevel,criteria A

-20~+70

(Referto"DeratingCurve")

20~90%RHnon-condensing

-40~+85 ,10~95%RH

0.05%/ (0~50

10~500Hz,2G10min./1cycle,60min.eachalongX, Y,Zaxes

108.4Khrsmin.MIL-HDBK-217F(25 )

127*76.2*34.6mm(L*W*H)

0.37Kg; 36pcs/14.3Kg/0.79CUFT

200WSingleOutputwithPFCFunction

PPS-200 se ri es

Universal AC input / Full range

Built-in active PFC function

High efficiency up to 90% (typ)

Protections: Short circuit / Overload / Over voltage /

PWM control and regulated

High power density 9.78W/inch

5"x3" compact size

ZVS technology to reduce power dissipation

Free air convection for 150W and 200W with 20.5 CFM forced air

3 years warranty

Over temperature

Built-in remote sense function

Features :

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC /25 /70%RH

SAFETY &

EMC

(Note4)

PROTECTION

ENVIRONMENT

CURRENTRANGE(convection)

CURRENTRANGE(20.5CFMFAN)

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

NOTE

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Heat Sink HS1,HS2 can not be shorted.

6. Length of set up time is measured at cold first start. Turning ON/OFF the power supply very quickly may lead to increase of the set up time.

For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

(as available on http://www.meanwell.com)

FileName:PPS-200-SPEC2011-11-29
