MechanicalSpecification
DeratingCurve OutputDeratingVSInputVoltage
FileName:PPS-200-SPEC2011-11-29
Unit:mm
AMBIENTTEMPERATURE( )
INPUTVOLTAGE(V)60Hz
90 115 125 135 155 264
100
90
80
70
60
50
40
LOAD(%)
LOAD(%)
-20 0 10 20 30 40 50 60 70
20
50
70
100
125
PWM&PFC
CIRCUIT
DETECTION
O.L.P.
EMI FILTER
RECTIFIERS
&
PFC
CIRCUIT
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
I/P
FG
CONTROL
O.V.P.
-V
BlockDiagram
fosc:100KHz
(HORIZONTAL)
DCOutputConnector(CN5):JST B8P-VHorequivalent
PinNo.
1~4
5~8
Assignment
-V
+V
MatingHousing
JST VHR
orequivalent
Terminal
JST SVH-21T-P1.1
orequivalent
ACInputConnector(CN1):JST B3P-VHorequivalent
PinNo.
1
3
2
Assignment
AC/L
AC/N
NoPin
MatingHousing
JST VHR
orequivalent
Terminal
JST SVH-21T-P1.1
orequivalent
HS1,HS2 can not be shorted
MatingHousing
Molex5051
orequivalent
Terminal
Molex4809
orequivalent
RemoteSense(CN3):Molex5045-02orequivalent
PinNo.
1
2
Assignment
RS-
RS+
3max.
200WSingleOutputwithPFCFunction
PPS-200 series
WithFAN
WithoutFAN
FAN
20.5CFM
HS1
HS2
direction
Airflow
50mm
4- 3.5
34.6 0.5
64.8
6.4
76.2
2
CN3
1
127
115.65
LED1
3
CN1
1
5
2
3
4
6
7
8
CN5
1
2
SVR1
