SPECIFICATION

PPT-125A PPT-125B PPT-125C PPT-125D

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE(convection)

CURRENTRANGE(18CFMFAN)

RATEDPOWER(convection)

RATEDPOWER(18CFMFAN)

OUTPUT

VOLTAGE ADJ.RANGE

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

POWERFACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

SAFETY STANDARDS

WORKINGTEMP.,HUMIDITY

WORKINGTEMP.

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

OVERVOLTAGE

ACCURRENT (Typ.)

3.3V 5V

CH2

12V

CH3

CH1

12V

CH2

-12V

CH3

CH1

15V

CH2

-15V

CH3

CH1

24V

CH2

12V

CH3

10A 8A 0.5A 11.5A 3A 0.5A 11A 2.5A 0.5A 7A 2.5A 0.5A

1~10A

1~12.5A

0.8~8A

0.8~10A

0.05~0.5A

0.05~0.63A

1~11.5A

1~14.38A

0.3~3A

0.3~3.75A

0.05~0.5A

0.05~0.63A

1~11A

1~13.75A

0.25~2.5A

0.25~3.13A

0.05~0.5A

0.05~0.63A

1~7A

1~8.75A

0.25~2.5A

0.25~3.13A

0.05~0.5A

0.05~0.63A

79W

98.81W

99.5W

124.46W

100W

125.15W

101W

126.43W

100mVp-p 100mVp-p 120mVp-p 100mVp-p 120mVp-p 120mVp-p 100mVp-p 150mVp-p 150mVp-p 100mVp-p 240mVp-p 120mVp-p

CH1:3.13~3.46V CH1:4.75~5.25V CH1:4.75~5.25V CH1:4.75~5.25V

3.0%

5.0%

3.0%

6.0%

5.0%

3.0% 5.0% 6.0% 3.0% 5.0% 6.0% 3.0% 5.0% 6.0%

0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5%

3.0% 3.0% 5.0% 3.0% 3.0% 5.0% 3.0% 3.0% 5.0%

1000ms,30ms/230VAC2000ms,30ms/115VACatfullload

24ms/230VAC24ms/115VACatfullload

90~264VAC127~370VDC

47~63Hz

PF>0.93/230VACPF>0.98/115VACatfullload

75% 78% 78% 78%

1.7A/115VAC0.75A/230VAC

COLDSTART 24A/230VAC

<2mA /240VAC

130~160% ratedoutputpower

CH1:3.6~4.45V CH1:5.75~6.75V CH1:5.75~6.75V CH1:5.75~6.75V

Protectiontype:Foldbackcurrentlimiting,recoversautomaticallyafterfaultconditionisremoved

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

UL60950-1, TUVEN60950-1approved

CompliancetoEN55022(CISPR22)ClassB, EN61000-3-2,-3

CompliancetoEN61000-4-2,3,4,5,6,8,11,EN55024,lightindustrylevel,criteria A

-20~+70

(Referto"DeratingCurve")

20~90%RHnon-condensing

-40~+85 ,10~95%RH

0.05%/ (0~50

10~500Hz,2G10min./1cycle,60min.eachalongX, Y,Zaxes

94.7Khrsmin.MIL-HDBK-217F(25 )

127*76.2*34.6mm(L*W*H)

0.37Kg;36pcs/14.3Kg/0.79CUFT

125W TripleOutputwithPFCFunction

Universal AC input / Full range

Built-in active PFC function

Protections: Short circuit / Overload / Over voltage

PWM control and regulated

High power density 6.117W/inch

LED indicator for power on

100% full load burn-in test

125W with 18CFM FAN

5"x3" compact size

3 years warranty

Features :

PPT-125 se ri es

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC /25 /70%RH

SAFETY &

EMC

(Note4)

PROTECTION

ENVIRONMENT

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Heat Sink HS1,HS2 & HS3 can not be shorted.

For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

(as available on http://www.meanwell.com)

CH1

OUTPUTNUMBER

FileName:PPT-125-SPEC2011-08-18

EMCIMMUNITY

EMCEMISSION
