SPECIFICATION

PT-45A PT-45B PT-45C

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

OUTPUT

VOLTAGE ADJ.RANGE

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

EFFICIENCY (Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT

WORKINGTEMP.

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

ACCURRENT (Typ.)

5V 12V

CH2

-5V

CH3

CH1

12V

CH2

-12V

CH3

CH1

15V

CH2

-15V

CH3

3A 2A 0.3A 3A 2A 0.3A 3A 1.6A 0.3A

0.4~5A 0.2~2.5A 0~0.5A 0.4~5A 0.2~2.5A 0~0.5A 0.4~5A 0.2~2.3A 0~0.5A

40.5W 42.6W 43.5W

Ratedoutputpowerforconvection;52Wwith18CFMmin.Forcedair

50mVp-p 120mVp-p 50mVp-p 50mVp-p 120mVp-p 100mVp-p 50mVp-p 120mVp-p 100mVp-p

CH1:4.75~5.5V

4.0% 7.0% 5.0% 4.0% 7.0% 5.0% 4.0% 7.0% 5.0%

1.0% 2.0% 1.0%

1.0%

1.0% 2.0% 1.0%

1.0%

1.0% 2.0% 1.0%

3.0% 4.0% 3.0% 4.0% 3.0% 4.0% 1.0%

800ms,20msatfullload

60msatfullload

90~264VAC127~370VDC

47~440Hz

75% 75% 75%

1A/115VAC0.7A/230VAC

COLDSTART 15A/115VAC30A/230VAC

<0.75mA

53~75W ratedoutputpower

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved.

-10~+60 (Refertooutputloadderatingcurve)

20~90%RHnon-condensing

-20~+85 ,10~95%RH

0.04%/ (0~50 )on+5Voutput

10~500Hz,2G10min./1cycle,Periodfor60min.eachalongX, Y,Zaxes

288.1Khrsmin.MIL-HDBK-217F(25 )

127*76*28mm(L*W*H)

0.21Kg;72pcs/17Kg/1.35CUFT

FileName:PT-45-SPEC 2007-03-14

CH1:5.75~6.75VDC

OVERVOLTAGE

SAFETY STANDARDS

HARMONICCURRENT

EMSIMMUNITY

CompliancetoEN55022(CISPR22)ClassB

Complianceto EN61000-3-2,-3

Complianceto EN55024,Lightindustrylevel,criteria AEN61000-4-2,3,4,5,6,8,11;ENV50204,

45W TripleOutputSwitchingPowerSupply

Features :

PT- 4 5 se ri es

ENVIRONMENT

SAFETY &

EMC

(Note4)

PROTECTION

EMICONDUCTION&RADIATION

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC1min.

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Mounting holes M1 and M2 should be grounded for EMI purposes.

Universal AC input/Full range

Low leakage current<0.5mA

Protections: Short circuit / Overload / Over voltage

Cooling by free air convection

100% full load burn-in test

Fixed switching frequency at 65KHz

2 years warranty

OUTPUTPOWER(max.)

UL60950-1, TUVEN60950-1 Approved

CH1

OUTPUTNUMBER
