Daikin EWAH290TZ-SSB1 [100/102] Technical specifications
![Daikin EWAH290TZ-SSB1 [100/102] Technical specifications](/views2/1672263/page100/bg64.png)
99/100
TECHNICAL SPECIFICATIONS
corrosion by atmospheric agents extending the life time (available on request).
Condenser fans The condenser fans used in conjunction with the condenser coils, shall be propeller type or
Brushless with glass reinforced resin blades for higher efficiencies and lower sound. Each fan shall be protected
by a fan guard.
•
The air discharge shall be vertical and each fan must be coupled to the electrical motor, supplied as standard
to IP54 and capable to work to ambient temperatures of - 20°C to + 65°C.
•
The condenser fans shall have as a standard a thermally protection by internal thermal motor protection and
protected by circuit breaker installed inside the electrical panel as a standard.
Refrigerant circuit The unit shall have one or two independent refrigerant circuits and one variable electrical
frequency driver per compressor (Inverter).
•
The circuit shall include as standard: electronic expansion device piloted by unit’s microprocessor control,
compressor suction and discharge shut-off valves, liquid line shut-off valve, economizer circuit with electronic
expansion valve, sight glass with moisture indicator, replaceable filter drier, charging valves, high pressure
switch, high and low pressure transducers, oil pressure transducer and insulated suction line.
Condensation control The units will be provided with an automatic control for condensing pressure which
ensures the working at low external temperatures down to - …………… °C, to maintain condensing pressure.
•
The compressor automatically unloads when abnormal high condensing pressure is detected. This to prevent
the shutdown of the refrigerant circuit (shutdown of the unit) due to a high-pressure fault.
Reduced Sound unit configurations (on request) The compressor shall be connected with unit’s metal base
frame by rubber anti vibration supports to prevent the transmission of vibrations to all metal unit structure, in
order to limit the unit noise emissions. The chiller shall be provided with an acoustical compressor enclosure
(according to the version). This enclosure shall be realized with a light, corrosion resisting aluminum structure
and metal panels. The compressor sound-proof enclosure shall be internally fitted with flexible, multi-layer, high
density materials.
Hydronic kit options (on request) The hydronic module shall be integrated in the chiller chassis without
increasing its dimensions and includes the following elements: centrifugal pump with motor protected by a circuit
breaker installed in control panel, water filling system with pressure gauge, safety valve, drain valve.
•
The hydronic module shall be assembled and wired to the control panel.
•
The water piping shall be protected against corrosion and freezing and insulated to prevent condensation.
•
A choice of two pump types shall be available:
-
in-line single pump
-
in-line twin pumps.
The unit should be able to operate in Primary only system with two-ways valve on terminals with Variable Primary
Flow control strategy (available as option on request).
Master/Slave the unit shell be able to operate in Master / Slave mode in order to be connected with other similar
unit (up to 4). The master unit shall manage the slaves units connected in series on the hydraulic plant with the
aim of optimize the running hours of each compressor.
Electrical control panel Power and control shall be located in the main panel that will be manufactured to
ensure protection against all weather conditions.
•
The electrical panel shall be IP54 and (when opening the doors) internally protected against possible accidental
contact with live parts.
•
The main panel shall be fitted with a main switch interlocked door that shuts off power supply when opening.
•
The power section will include compressors and fans protection devices, fans starters and control circuit power
supply.
Controller The controller will be installed as standard and it will be used to modify unit set-points and check
control parameters.
•
A built-in display will shows chiller operating status plus temperatures and pressures of water, refrigerant and
air, programmable values, set-points.
•
A sophisticated software with predictive logic, will select the most energy efficient combination of compressors,
EEXV and condenser fans to keep stable operating conditions to maximize chiller energy efficiency and reliability.
•
The controller will be able to protect critical components based on external signals from its system (such as
motor temperatures, refrigerant gas and oil pressures, correct phase sequence, pressure switches and
evaporator). The input coming from the high pressure switch cuts all digital output from the controller in less
than 50ms, this will be an additional security for the equipment.
•
Fast program cycle (200ms) for a precise monitoring of the system.
•
Floating point calculations supported for increased accuracy in P/T conversions.
