TECHNICAL SPECIFICATIONS
EWAH~TZ-XSB
MODEL
EWAH430TZ
XSB2
EWAH480TZ
XSB2
EWAH580TZ
XSB2
EWAH620TZ
XSB2
EWAH710TZ
XSB2
COOLING PERFORMANCE
Capacity - Cooling
kW
428
482
574
620
714
Capacity control - Type
Stepless
Stepless
Stepless
Stepless
Stepless
Capacity control - Minimum capacity %
14.3
12.5
10.8
10
10
Unit power input - Cooling
kW
125
144
164
181
209
EER
3.42
3.33
3.50
3.41
3.40
ESEER
5.06
5.05
5.05
5.08
5.13
IPLV
5.90
6.00
6.01
6.20
6.21
SEASONAL ENERGY EFFICIENCY ****
SEER (12/7°C)
5.157
5.23
5.449
5.522
5.593
η
s cool
(12/7°C) %
203.28
206.2
214.96
217.88
220.72
DIMENSIONS
Height
mm
2540
2540
2540
2540
2540
Width
mm
2282
2282
2282
2282
2282
Length
mm
6786
7684
6877
7787
8687
WEIGHT
Unit Weight
kg
5004.6
5748.6
5720
6364.8
7140.2
Operating Weight
kg
5237.6
5981.6
6021
6656.8
7625.2
WATER HEAT EXCHANGER
Type *
S&T
S&T
S&T
S&T
S&T
Water Volume
l
233
233
301
292
485
Water flow rate
l/s
20.4
23.0
27.4
29.6
34.1
Water pressure drop***
kPa
34.2
26.3
24.7
31.1
25.6
AIR HEAT EXCHANGER
Type *
MCH
MCH
MCH
MCH
MCH
FAN
Type *
DPT
DPT
DPT
DPT
DPT
Drive *
VFD
VFD
VFD
VFD
VFD
Diameter
mm
800
800
800
800
800
Nominal air flow
l/s
61068
69792
61068
69792
78516
Quantity
No.
14
16
14
16
18
Speed
rpm
700
700
700
700
700
Motor input
kW
12.1
13.8
12.1
13.8
15.6
COMPRESSOR
Oil charge
l
20.0
20.0
28.0
28.0
28.0
Quantity
No.
2
2
2
2
2
SOUND LEVEL**
Sound Power - Cooling
dB(A)
100
102
104
104
104
Sound Pressure level@1m distance -
dB(A)
Cooling
80.0
80.0
83
83
82
REFRIGERANT CIRCUIT
Refrigerant type
R1234ze
R1234ze
R1234ze
R1234ze
R1234ze
Refrigerant charge
kg
84.6
97.6
102
116.8
131.2
N. of circuits
No.
2
2
2
2
2
PIPING CONNECTIONS
Evaporator water inlet/outlet
mm
168.3
168.3
168.3
168.3
219.1
All the performances (Cooling capacity, unit power input in cooling and EER) are based on the following conditions: evaporator 12.0/7.0°C; ambient
35.0°C, unit at full load operation; operating fluid: Water; fouling factor = 0.
(*)PHE: Plate Heat Exchanger; S&T: Single Pass Shell & Tube; MCH: Microchannel; DPT: Direct Propeller Type; DOL: Direct On Line - VFD: Inverter - BRS:
Brushless
(**) Sound power level (referred to evaporator 12/7°C, ambient 35°C full load operation) are measured in accordance with ISO 9614 and Eurovent 8/1
for Eurovent certified units. The certification refers only to the overall sound power level, the sound pressure is calculated from the sound power level and
are for information only and not considered binding. The minimum capacity indicated is referred to unit operating at standard Eurovent conditions.
Dimensions and weights are for indication only and not considered binding. Before designing the installation, consult the official drawings available from
the factory at request. All the data are referred to standard unit without options. All data are subject to change without notice.
(***) The value refers to the pressure drops in the evaporator only.
(****) In accordance with standard EN14825:2013, comfort low temperature, average climate. SEER and ηs values applicable Ecodesign regulation: (EU)
No 2016/2281.
