GV-NX62TC Series Graphics Accelerator - 18 -
English
GeForce 6200 TurboCache(TM) properties
This page shows the Adapter, System and
Driver version information.
You can select other properties from the pop-out menu.
After pressing the "Advanced" button in Settings, you'll see the Plug and Play Monitor and
NVIDIA GeForce 6200 TurboCache(TM) Properties dialog box. Click the GeForce 6200
TurboCache(TM) tab. (You can also click the NVIDIA icon on the taskbar and select Nvidia Display
to access the Geforce 6200 TurboCache(TM) properties page.)
3.1.6. Display Properties Pages
To access Display Properties pages, right-click the GBT icon on the taskbar and select
Display Properties or right-click on Desktop and then select Properties. The Display
Properties dialog box shows the information of display adapter, color, the range of display
area, and the refresh rate.
Settings (Resolutions and Color depth for Windows)
You may adjust the screen resolution and color quality settings in this dialog box.
You can click the item to change the color quality.
You can move the slider to change the resolution.
To access more advanced options, click the Advanced button.
Click the Advanced button for adapter and setting.
