SPECIFICATION

RPS-75-3.3 RPS-75-5 RPS-75-12 RPS-75-15 RPS-75-24 RPS-75-36 RPS-75-48

MODEL

DCVOLTAGE

RATEDCURRENT

CURRENTRANGE

RATEDPOWER

PEAKLOAD(23.5CFM)

OUTPUT

VOLTAGE ADJ.RANGE

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

FREQUENCY RANGE

EFFICIENCY(Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT Note.7

WORKINGTEMP.

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVERLOAD

ACCURRENT (Typ.)

3.3V

24V 36V 48V

15A 3.2A 2.1A 1.6A

0~20A 0~18.7A 0~8.3A 0~6.7A 0~4.2A 0~2.8A 0~2.1A

49.5W

66W

70W

93.5W

75.6W

99.6W

75W

100.5W

76.8W

100.8W

75.6W

100.8W

76.8W

100.8W

80mVp-p

2.9~3.6V

80mVp-p

4.75~5.5V

120mVp-p

11.4~13.2V

150mVp-p

13.5~16.5V

240mVp-p

22.8~27.6V

300mVp-p

34.2~39.6V

300mVp-p

45.6~52.8V

2.0% 2.0% 1.0% 1.0% 1.0% 1.0% 1.0%

0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5%

1.5% 1.5% 1.0% 1.0% 1.0% 1.0% 1.0%

500ms,30ms/230VAC500ms,30ms/115VACatfullload

80ms/230VAC20ms/115VACatfullload

90~264VAC127~370VDC

47~63Hz

73% 78% 83% 85% 86% 86%

1.5A/115VAC1A/230VAC

COLDSTART 25A/115VAC50A/230VAC

140~180%ratedoutputpower

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved.

3.8~4.46V 5.75~6.75V 13.8~16.2V 17.25~20.25V 27.6~32.4V 41.4~48.6V 55.2~64.8V

Protectiontype:Shutdowno/pvoltage,re-powertorecover

-20~+70 (Referto"DeratingCurve")

20~90%RHnon-condensing

-40~+85 ,10~95%RH

0.03%/ (0~45

10~500Hz,2G10min./1cycle,periodfor60min. eachalongX, Y,Zaxes

446.8Khrsmin.MIL-HDBK-217F(25 )

127*76.2*31mm(L*W*H)

0.26Kg;63pcs/16.3Kg/1.35CUFT

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. Length of set up time is measured at cold first start. Turning ON/OFF the power supply may lead to increase of the set up time.

6. Heat Sink HS1,HS2,HS3 can not be shorted.

7. .

For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

(as available on http://www.meanwell.com)

Touch current was measured from primary input to DC output

FileName:RPS-75-SPEC2012-05-22

OVERVOLTAGE

SAFETY STANDARDS

RPS-75 se ri es

Features :

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

RIPPLE&NOISE(max.) Note.2

VOLTAGETOLERANCE Note.3

ENVIRONMENT

SAFETY &

EMC

(Note4)

PROTECTION

Universal AC input/Full range

Low leakage current <100 A

Protections: Short circuit / Overload / Over voltage

Free air convection for rated power and 23.5CFM forced air

convection for peak load

ANSI/AAMI ES60601-1/IEC60601-1/EN60601-1 medical safety approved

No load power consumption<0.75W

Fixed switching frequency at 65KHz

3 years warranty

CompliancetoEN55011(CISPR11),EN55022(CISPR22)ClassB,EN61000-3-2,-3

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC/25 /70%RH

ANSI/AAMIES60601-1, TUVEN60601-1,IEC60601-1approved

I/P-O/P:4KVACI/P-FG: O/P-FG:1.5KVAC2KVAC

75WSingleOutputMedical Type

5V 12V 15V

14A 6.3A 5A

82%

CompliancetoEN61000-4-2,3,4,5,6,8,11,EN55024,EN60601-1-2,EN61000-6-2,EN61204-3,heavyindustrylevel,EN61204-3medicallevel,criteria A

EMCIMMUNITY

EMCEMISSION

Earthleakagecurrent<100 A/264VAC, Touchleakagecurrent<100 A/264VAC
