MEAN WELL RPS-75-15 [2/2] Series

MEAN WELL RPS-75-15 [2/2] Series
FileName:RPS-75-SPEC 2012-05-22
Unit:mm
fosc:65KHz
LOAD(%)
BlockDiagram
MechanicalSpecification
AMBIENTTEMPERATURE( )
(HORIZONTAL)
-20 0 10 20 30 40 50 60 70
20
50
80
100
133
OutputDeratingVSInputVoltage
INPUTVOLTAGE(VAC)60Hz
90 10095 120115 160140 200180 240220 264
LOAD(%)
90
100
80
70
60
50
40
DCOutputConnector(CN2):JST B8P-VHorequivalent
PinNo.
1,2,3,4
5,6,7,8
Assignment
+V
-V
MatingHousing
JST VHR
orequivalent
Terminal
JST SVH-21T-P1.1
orequivalent
CIRCUIT
DETECTION
O.L.P.
EMI
FILTER
RECTIFIERS
&
FILTER
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
ACInputConnector(CN1):JST B3P-VHorequivalent
PinNo.
1
2
3
Assignment
AC/N
NoPin
AC/L
MatingHousing
JST VHR JST SVH-21T-P1.1
orequivalent orequivalent
Terminal
ConvectionCooling
23.5CFM ForcedairCooling
+S
-S
3.3V,5V
Others
JST XHP
JST SXH-001T-P0.6
23.5CFMmin.
15cm
FAN
5.6
115.8
127
DeratingCurve
3max.
ACFUSE
T2.5/250V
HS1,HS2,HS3 can not be shorted
HS2
HS1
HS3
RPS-75 series
75WSingleOutputMedical Type
RemoteSense(CN3):JST B2B-XHorequivalent
PinNo.
1
2
MatingHousing
orequivalent
Terminal
orequivalent
Assignment
RS+
RS-
CN2
3
CN1
1
2
1
8
7
6
4
3
2
5
CN3
4- 3.8
1
2
5.7
64.75
76.2
31
FS2
FS1
