SPECIFICATION

RPS -160-5 RPS -160-12 RPS -160-15 RPS -160-24 RPS -160-48

MODEL

DCVOLTAGE

RATEDCURRENT(20.5CFM)

RATEDPOWER(convection) Note.7

CURRENTRANGE(20.5CFM)

OUTPUT

VOLTAGE ADJ.RANGE

LINEREGULATION

LOADREGULATION

SETUP,RISETIME

HOLDUP TIME (Typ.)

VOLTAGERANGE

Note.6

FREQUENCY RANGE

POWERFACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

INRUSHCURRENT (Typ.)

LEAKAGECURRENT Note.9

SAFETY STANDARDS

WORKINGTEMP.

REMOTESENSE

WORKINGHUMIDITY

STORAGETEMP.,HUMIDITY

TEMP.COEFFICIENT

VIBRATION

OVERLOAD

OVERVOLTAGE

OVERTEMPERATURE

ACCURRENT (Typ.)

5V 12V 15V 24V 48V

30A 12.9A 10.3A 6.5A 3.25A

0~20A

0~30A

0~9.1A

0~12.9A

0~7.3A

0~10.3A

0~4.6A 0~2.3A

0~6.5A 0~3.25A

103W

155W

112.2W

159.8W

112.5W

159.5W

113.4W 113.4W

161W 161W

100mVp-p

120mVp-p

150mVp-p

250mVp-p

CH1:4.5~5.5V CH1:10.8~13.2V CH1:13.5~16.5V CH1:22~27V CH1:43.2~52.8V

4.0% 3.0% 3.0% 2.0% 2.0%

0.5% 0.5% 0.5% 0.5% 0.5%

1.0% 1.0% 1.0% 1.0% 1.0%

1800ms,30ms/230VAC3 atfullload500ms,30ms/115VAC

90~264VAC127~370VDC

16ms/230VAC/115VACatfullload

47~63Hz

PF>0.93/230VACPF>0.98/115VACatfullload

85% 87% 87% 87% 88%

2A/115VAC1.1A/230VAC

COLDSTART 35A/115VAC70A/230VAC

105~135% ratedoutputpower

5.75~6.75V

110 (5V),105 (12V,15V,24V,48V)(TSW1:detectonheatsinkofpowertransistor)

95 (5V),90 (12V,15V,24V,48V)(TSW2:detectonheatsinkofpowertransistor)

13.8~16.2V 17.25~20.25V 27.6~32.4V 55.2~64.8V

Protectiontype: Hiccupmode,recoversautomaticallyafterfaultconditionisremoved

Protectiontype:Shutdowno/pvoltage,re-powerontorecover

Protectiontype:(TSW2)Shutdowno/pvoltage,re-powerontorecover

Protectiontype:(TSW1)Shutdowno/pvoltage,recoversautomaticallyaftertemperaturegoesdown

ANSI/AAMIES60601-1, TUVEN60601-1approved

-20~+70

(Referto"DeratingCurve")

5~15V

20~90%RHnon-condensing

-40~+85 ,10~95%RH

0.03%/ (0~50 )

10~500Hz,2G10min./1cycle,60min.eachalongX, Y,Zaxes

160WSingleOutputMedical Type

RPS-160 se ri es

Universal AC input / Full range

Built-in active PFC function

Protections: Short circuit / Overload / Over voltage /

5"x3" compact size

Free air convection for 110W and 160W with 20.5 CFM forced air

With power good and fail signal output

3 years warranty

Over temperature

Built-in remote sense function for 5~15V

No load power consumption under 0.75W by PS-ON control

(G model)

Standby 5V@0.8A with fan, @0.6A without fan (G model)

Features :

WITHSTANDVOLTAGE

ISOLATIONRESISTANCE

I/P-O/P:4KVACI/P-FG: O/P-FG:0.5KVAC

2KVAC

I/P-O/P,I/P-FG,O/P-FG:100MOhms/500VDC /25 /70%RH

SAFETY &

EMC

(Note4)

PROTECTION

ENVIRONMENT

CURRENTRANGE(convection)

RIPPLE&NOISE(max.) Note.2

RATEDPOWER(20.5CFM) Note.8

VOLTAGETOLERANCE Note.3

POWERGOOD/POWERFAIL

Poweron:PS-ON="Hi"or">2~5V";Poweroff:PS-ON="Low"or"<0~0.5V"

500ms>PG>10msPF>1ms

FUNCTION

CompliancetoEN55011(CISPR11),EN55022(CISPR22)ClassB,EN61000-3-2,-3

MTBF

DIMENSIONOTHERS

CompliancetoEN61000-4-2,3,4,5,6,8,11,EN55024,EN60601-1-2,EN61204-3,medicallevel,criteria A

230.5Khrsmin.MIL-HDBK-217F(25 )

127*76.2*34.6mm(L*W*H)

PACKING

0.32Kg;36pcs/12.5Kg/0.79CUFT

NOTE

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 2

ed at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets

EMC directives.

5. HS1,HS2 & HS3 can not be shorted.

6. Derating may be needed under low input voltages. Please check the derating curve for more details.

7. The rated power includes 5Vsb @ 0.6A.

8. The rated power includes 5Vsb @ 0.8A.

5 of ambient temperature.

2. Ripple & noise are measur

. .

For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.

(as available on http://www.meanwell.com)

Touch current was measured from primary input to DC output

RPS 160

consumption<0.75W

G:With5Vsb&noloadpower

Blank:Basicfunction(without5Vsb)

PS-ONINPUTSIGNAL (Gmodel)

5VSTANDBY (Gmodel)

5VSB:5V@0.6A withoutfan,0.8A withfan20.5CFM;tolerance 2%,ripple:50mVp-p(max.)

EMCIMMUNITY

EMCEMISSION

Earthleakagecurrent<200 A/264VAC, Touchleakagecurrent<100 A/264VAC
