■ Model Encoding

■ Description

MPM-90 is a 90W high density and small size (87x52x29.5mm) AC/DC PCB-mount module type medical

grade power supply . It features the operation for 80~264VAC, a low no load power consumption less

than 0.1W, a high efficiency up to 93%, Class (no FG) double insulation, outstanding dissipation, Ⅱ

2~5G anti-vibration by model, high EMC performance, 4KVAC isolation, etc. The design observes IEC EN60601 1/-

and ANSI/AAMI ES60601 1version three with 2 x MOPP level and ultra-low leakage current (< A). It is very - 100μ

3.43" 2.05" x compact size

PCB,chassis or screw terminal mounting version

Medical safety approved (2 x MOPP) to according

ANSI/AAMI ES60601-1 and IEC/EN60601-1

Suitable for BF application with appropriate system consideration

No load power consumption<0.1W

Extremely low leakage current

℃Wide operating temp. range -30 ~ +80

EMI Class B without additional components

Ⅱ

Isolation Class

Protections: Short circuit / Overload / Over voltage

No minimum load required

Operating altitude up to 4000 meters( Note.7)

100W peak(10 sec.)

3 years warranty

■ Features

90W AC-DC High Reliable PCB-Mount Green Medical Power Module

MPM-90series

Output voltage

Rated wattage

Series name

Portable medical device

Mobile clinical workstation

Medical computer monitor

Medical examination instrument

■ Applications

EN 60601-1

IEC 60601-1

IEC60601-1EN60601-1ANSI/AAMI ES60601-1

suitable for BF (patient contact) type medical device or relevant equipment.

-12MPM - 90

ST : Screw terminal style

Blank : PCB mounting style

{

File Name:MPM-90-SPEC 2020-10-20

(MPM-90-xxST)(MPM-90)

TPTC004
