MPM-90 series
Mechanical SpecificationMechanical Specification
Case No.IRM60 Unit:mm
PCB mounting style (MPM 90)-
2-2ψ
2-1ψ
3.5 1mm±
40.75
52
6.75
5
5.5
BOTTOM
VIEW
AC/N
AC/L
5.7
76
87
29.5
90W AC-DC High Reliable PCB-Mount Green Medical Power Module
(MPM 90 xxST)--Screw terminal style
AC/L, AC/N P/N diameter:1ψ
+V , -V P/N diameter:2
oo
ψ
4- 3.5ψ
109
98
6.7
33.5
33
52
AC/N AC/L
7.5
555
Installation Manual
Please refer to : http://www.meanwell.com/manual.html
File Name:MPM-90-SPEC 2020-10-20
TOP
VIEW
-Vo+Vo+Vo-Vo
-Vo
+Vo
