MEAN WELL PM-05-15 [2/2] Series
![MEAN WELL PM-05-3.3 [2/2] Series](/views2/1678475/page2/bg2.png)
FileName:PM-05-SPEC2010-07-19
fosc:67KHz
AMBIENTTEMPERATURE( )
LOAD(%)
(HORIZONTAL)
BlockDiagram
MechanicalSpecification
-20 0 10 20 30 40 50 60 70
20
40
60
80
100
5WOutputSwitchingPowerSupply
FILTER
I/P
EMI
FILTER
RECTIFIERS
&
RECTIFIERS
CONTROL
SWITCH-
PWM
ING
POWER
DETECTION
CIRCUIT
&
FILTER
+V
-V
OutputDeratingVSInputVoltage
INPUTVOLTAGE(VAC)60Hz
85 10095 120115 160140 200180 240220 264
LOAD(%)
Ta=25
90
100
80
70
60
50
40
CaseNo.948A Unit:inch(mm)
0.138"
(3.5 1mm)
0.041"(1.05mm)
DeratingCurve
PM-05 series
AC/N AC/L
+V-V
VIEW
BOTTOM
0.295"
(7.5mm)
0.689"(17.5mm)
1.97"(50mm)
0.306"(7.8mm)
1.85"(47mm)
2.475"(62.85mm)
0.59"(15mm)0.789"(20.04mm)
0.776"(19.7mm)
