MEAN WELL PM-15-3.3 [2/2] Series

MEAN WELL PM-15-3.3 [2/2] Series
fosc:67KHz
BlockDiagram
MechanicalSpecification
FILTER
I/P
EMI
FILTER
RECTIFIERS
&
RECTIFIERS
CONTROL
PWM
DETECTION
CIRCUIT
&
FILTER
+V
-V
FileName:PM-15-SPEC 2012-11-28
AMBIENTTEMPERATURE( )
LOAD(%)
(HORIZONTAL)
-20 0 10 20 30 40 50 60 70
20
40
60
80
100
OutputDeratingVSInputVoltage
INPUTVOLTAGE(VAC)60Hz
85 10095 120115 160140 200180 240220 264
LOAD(%)
90
100
80
70
60
50
40
0.041"(1.05mm)
DeratingCurve
0.138"
(3.5 1mm)
SWITCHING
POWER
15WOutputSwitchingPowerSupply
PM-15 series
CaseNo.950A Unit:inch(mm)
VIEW
BOTTOM
AC/N AC/L
+V-V
0.256"
(6.5mm)
0.788"(20mm)
2.09"(53mm)
0.256"(6.5mm)
2.441"(62mm)
2.95"(75mm)
0.906"
(23.01mm)
0.59"
(15mm)
0.89"(22.7mm)
