5
EN
Description of the Connectors
Picture 3. Description of the Connectors
(TV43-FS2)
1. PC Audio – line audio input (operates
when a video source is connected to the
VGA connector).
2. VGA video input.
3. RJ45 to connect a wired network.
4. VIDEO – RCA connector of the analogue
video input.
5. L – RCA connector of the left channel
audio input.
6. R – RCA connector of the right channel
audio input.
7. HDMI 1 input.
8. RF(S2) - connector for a satellite
antenna signal connection.
9. RF(T2) – connector for a TV
broadcasting antenna connection.
10. HDMI 2 input.
11. HDMI 3 input.
12. USB 1 connector.
13. CI+ a slot to connect add-in modules
14. EARPHONE – connector of the line audio
output to connect earphones or external
acoustic devices.
15. USB 2 connector.
Picture 4. Description of the Connectors
(TV43-US2, TV49-US2, TV55-US2, TV65-US2,
TV70-US2)
1. RJ45 to connect a wired network.
2. VGA video input.
3. VIDEO – RCA connector of the analogue
video input.
4. L – RCA connector of the left channel
audio input.
5. R – RCA connector of the right channel
audio input.
6. RF(S2) – connector for a satellite
antenna signal connection.
7. RF(T2) – connector for a TV
broadcasting antenna connection.
8. OPTICAL – connector of the optical
audio output.
9. HDMI 1 (ARC) input.
10. HDMI 2 input.
11. HDMI 3 input.
12. USB 1 connector.
13. USB 2 connector.
14. PC Audio – line audio input (operates
when a video source is connected to the
VGA connector).
15. mini YPbPr.
16. EARPHONE – connector of the line audio
output to connect earphones or external
acoustic devices.
17. CI+ a slot to connect add-in modules.
Picture 2. Description of the Connectors
(TV22-HS2, TV24-HS2*, TV32-HS2, TV32-FS2,
TV40-HS2, TV40-FS2*)
1. RJ45 to connect a wired network.
2. VIDEO – RCA connector of the analogue
video input.
3. L – RCA connector of the left channel
audio input.
4. R – RCA connector of the right channel
audio input.
5. mini YPbPr.
6. OPTICAL – connector of the optical
audio output.
7. RF(T2) – connector for a TV
broadcasting antenna connection.
8. RF(S2) – connector for a satellite
antenna signal connection.
9. HDMI 1 (ARC) input.
10. HDMI 2 input.
11. USB 1 connector.
12. USB 2 connector.
13. EARPHONE – connector of the line audio
output to connect earphones or external
acoustic devices.
14. CI+ a slot to connect add-in modules.
*The number and type of connectors shown in the gure may be changed by the manufacturer without further notication
