SPECIFICATION

MODEL RS-25-3.3 RS-25-5 RS-25-12 RS-25-15 RS-25-24 RS-25-48

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

OUTPUT VOLTAGE ADJ. RANGE

LINE REGULATION Note.4

LOAD REGULATION Note.5

INPUT

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

SAFETY STANDARDS

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

3.3V 5V 12V 15V 24V 48V

6A 5A 2.1A 1.7A 1.1A 0.57A

0 ~ 6A 0 ~ 5A 0 ~ 2.1A 0 ~ 1.7A 0 ~ 1.1A 0 ~ 0.57A

19.8W 25W 25.2W 25.5W 26.4W 27.36W

2.85 ~ 3.6V 4.75 ~ 5.5V 10.8 ~ 13.2V 13.5 ~ 16.5V 22 ~ 27.6V 42 ~ 54V

±3.0% ±2.0% ±1.0% ±1.0% ±1.0% ±1.0%

±0.5% ±0.5% ±0.5% ±0.5% ±0.5% ±0.5%

±2.0% ±1.0% ±0.5% ±0.5% ±0.5% ±0.5%

3.8 ~ 4.45V 5.75 ~ 6.75V 13.8 ~ 16.2V 17.25 ~ 20.25V 27.6 ~ 32.4V 55.2 ~ 64.8V

COLD START 30A/230VAC

<2mA / 240VAC

110 ~ 180% rated output power

Protection type : Hiccup mode, recovers automatically after fault condition is removed

-20 ~ +70℃ (Refer to "Derating Curve")

20 ~ 90% RH non-condensing

-40 ~ +85℃, 10 ~ 95% RH

±0.03%/℃ (0 ~ 50℃)

10 ~ 500Hz, 5G 10min./1cycle, period for 60min. each along X, Y, Z axes

I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH

℃









  

    



VOLTAGE TOLERANCE Note.3

Compliance to EN61000-4-2,3,4,5,6,8,11, light industry level, criteria A

0.2Kg; 60pcs/13Kg/0.46CUFT

EMC IMMUNITY

EMC EMISSION

UL60950-1, TUV EN60950-1 , CCC GB4943 approved
