MEAN WELL RS-25-12 [2/2] Series
![MEAN WELL RS-25-24 [2/2] Series](/views2/1679628/page2/bg2.png)
1
LED
+V ADJ.
2
3
5
4
14 max.
7.62
6
2-M3
66.5
10.5
55
78
2.75
14
28
2-M3 L=3
25.4
51
Mechanical Specification
Case No.931A Unit:mm
AMBIENT TEMPERATURE (℃)
LOAD (%)
-20 0 2010 30 40
20
40
80
60
100
60 7050
Terminal Pin No. Assignment
Pin No. Pin No.
1
2
4
3
5
Assignment Assignment
DC OUTPUT -V
DC OUTPUT +V
FG
AC/L
AC/N
Block Diagram
fosc : 60KHz
CONTROL
-V
+V
RECTIFIERS
&
FILTER
SWITCHING
POWER
FILTER
&
RECTIFIERS
O.L.P.
DETECTION
CIRCUIT
PWM
FG
I/P
FILTER
EMI
3.3V only
Others
(HORIZONTAL)
Derating Curve Output Derating VS Input Voltage
INPUT VOLTAGE (VAC) 60Hz
88 95 120 140100 115 200 220160 180 240 264
LOAD (%)
90
100
80
70
60
50
40
25W Single Output Switching Power Supply
RS-25 series
File Name:RS-25-SPEC 2017-05-11
