Function Manual

EXTERNAL VOLTAGE (DC)

PIN3 PV

PIN4 GND

1. Remote Sense

Sense lines should be twisted in pairs to minimize noise pick-up.

※ The Remote Sense compensates voltage drop on the load wiring up to 0.5V

◎ The signal should be connected to the positive terminal of the load whereas signal to the negative terminal.+S -S

LOAD

-V

PIN2 -S

PIN1 +S

3. Remote ON-OFF Control

The power supply can be turned ON/OFF individually or along with other units by using the "Remote ON-OFF" function.

PIN7 Remote ON-OFF

PIN11 +5V-AUX

Between andRemote ON-OFF +5V-AUX

Switch Short

Switch Open

Power Supply Status

OFF

switch

File Name:RSP-2000-SPEC 2017-07-14

2000W Power Supply with Single Output

RSP-2000 series

◎+S +V -S -V& , & also need to be connected on CN501.

OUTPUT VOLTAGE(%)

EXTERNAL VOLTAGE (DC)

100

115

Vout

0.40

for 12V model

for 24V,48V

model

1 2 3 4 4.7 5

40 60 80 100 115

100

OUTPUT CURRENT (%)

OUTPUT VOLTAGE (%)

Non-Linear

※ In addition to the adjustment via the built-in potentiometer, the output voltage can be trimmed to 40~115% of the nominal voltage by applying

EXTERNAL VOLTAGE.

2. Output Voltage Programming (or, PV / remote voltage programming / remote adjust / margin programming / dynamic voltage trim)

◎ The rated current should change with the

Output Voltage Programming accordingly.

PIN2 -S

PIN1 +S

CN501

-V
