2000W Power Supply with Single Output

RSP-2000 series

File Name:RSP-2000-SPEC 2017-07-14

Pin No. Function

Description

1,2

3,4

Differential digital signal for parallel control.

※Control Pin No.Assignment : HRS DF11-6DP-2DSA or equivalent(CN502)

Mating Housing

Terminal

HRS DF11-6DS or equivalent

HRS DF11-**SC or equivalent

Function

DC-OK

DC-NG

T-OK

T-ALARM

LED

GREEN

RED

Description

When output voltage 80% 5% of Vo rated.≧±

When output voltage 80% 5% of Vo rated.≦±

When the internal temperature (TSW1 & TSW2 short) is within safe limit

When the internal temperature (TSW1 or TSW2 open) exceeds the limit of temperature alarm

※LED Indicators & Corresponding Signal at Function Pins

Signal

0 ~ 0.5V

4.5 ~ 5.5V

0 ~ 0.5V

4.5 ~ 5.5V

Power Supply Output

OFF

*Signal between function pin and "GND-AUX".

Installation Manual

Please refer to : http://www.meanwell.com/manual.html

※AC Input Terminal Pin No. Assignment

※DC Output Terminal Pin No. Assignment

※Control Pin No.Assignment (CN504):

Pin No.

Assignment

Diagram

Mxa imum mounting torque

18Kgf-cm

10Kgf-cm

AC/N

+V, -V

AC/L

5,6 GND

These pins connect to the negative terminal (-V).

Pin No.

1,2

Function

Terminal

resistance

Description

CN504 is the selector of terminal resistor that is designed for DA/DB signals and parallel control function.
