- 12 - Hardware Installation
Socket
Socket
Storage Front side: 12 x 3.5" SATA/SAS hot-swappable HDD/SSD bays
2.5" HDD/SSD supported
12 x SATA ports by default setting
SAS card is required for SAS devices support
Socket
Socket
SATA 2 x 7-pin SATA III 6Gb/s with SATA DOM supported
By using pin_8 or external cable for power function
Socket
Socket
SAS Supported via add-on SAS Card
Socket
Socket
Support RAID
Function
Intel® SATA RAID 0/1/10/5
Socket
Socket
Internal
Connectors
2 x Power supply connectors
5 x SlimSAS connectors
2 x SATA 7-pin connectors
2 x CPU fan headers
1 x USB 3.0 header
1 x TPM header
1 x VROC connector
1 x Front panel header
1 x HDD back plane board header
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery jumper
Socket
Socket
Front Panel
LED/Buttons
2 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs
Socket
Socket
Rear Panel I/O 2 x USB 3.0
1 x VGA
1 x COM (as an option)
2 x RJ45
1 x MLAN
1 x ID button with LED
Socket
Socket
Backplane I/O 12 x SATA/SAS ports
Bandwidth: SATAIII 6Gb/s or SAS 12Gb/s per port
Socket
Socket
TPM 1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM00
