22
23
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USER GUIDE ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USER GUIDE
ХОЛОДИЛЬНИК
REFRIGERATOR-FREEZER
ХОЛОДИЛЬНИК
REFRIGERATOR-FREEZER
power cord is damaged, have it replaced by an authorized service center.
• This refrigerator should be properly grounded for your safety. The power cord of this
refrigerator is equipped with a three-prong plug which mates with standard three
prong wall outlets to minimize the possibility of electrical shock.
• Do not, under any circumstances, cut or remove the third ground prong from the
power cord supplied.
• This refrigerator requires a standard 220-240 V A.C. ~/50 Hz electrical outlet with
three-prong ground.
• This refrigerator is not designed to be used with an inverter.
• The cord should be secured behind the refrigerator and not left exposed or dangling
to prevent accidental injury.
• Never unplug the refrigerator by pulling the power cord. Always grip the plug firmly
and pull straight out from the receptacle.
• Do not use an extension cord with this appliance. If the power cord is too short, have
a qualified electrician or service technician install an outlet near the appliance. Use of
an extension cord can negatively affect the performance of the unit.
Before Plugging in! You must check that you have a socket which is
compatible with the plug supplied with the unit.
Before switching on! Do not turn on until two hours after moving the unit.
DO NOT SWITCH ON UNTIL FOUR HOURS AFTER MOVING THE FRIDGE/
FREEZER. The coolant fluid needs time to settle. If the appliance is switched off
at any time, wait 30 minutes before switching back on to allow the coolant fluid
to settle.
Interior Accessories
Various glass or plastic storage shelves are included with your appliance — different
models have different combinations.
You should always slide one of the full size glass storage shelves into the lowest set
of guides, above the fruit and vegetable containers, and keep it in this position. To do
this, pull the storage shelf forward until it can be swiveled upwards or downwards and
removed.
Note: Please do the same in reverse to insert the shelf at a different height.
In order to make the most of the volume of the fresh food storage compartment and
frozen-food storage compartment, the user can remove one or more shelves, drawers,
out of the appliance, according to your daily use.
START
Control system schemes
1. Clean the parts of the refrigerator with lukewarm water containing a littleneutral
detergent and with clear water, and wipe them dry.
Notes: Electric parts of the refrigerator can only be wiped by dry cloth.
2.Turn on electricity. The compressor begin to work.
3.Open the door 30 minutes later, if the temperature in the refrigerator decreased
obviously, it shows that the refrigerator system works well. When the refrigerator operates
for a period of time, the temperature controller will automatically set the temperature
within limits it opens.
The display is located in the middle of the refrigerator door. Please refer to the below
figure for the layout.
Intelligence
Under intelligence, it is 4°C in the refrigerator and -18°C in the freezer.
Temperatures cannot be changed and you can click the temperature zone button to
check the temperature.
1) To enter intelligence
Click “option” until it flickers and then click “OK” to enter this function.
2) To quit intelligence
Under intelligence, click “option” until it goes to intelligence, click “OK” to quit this
function and the light goes off.
OFF
Fast
Fast
Cooling
Freezing
Smart ECO
Vacation
Fridge
Freezer
Function
OK
introduction of the buttons:
Fridge: to set the refrigerator temperature;
Freezer: to set the freezer temperature;
Function: to choose functions of fast cooling, fast freezing, intelligence
and vacation;
OK: to enter or to quit the existing function function setting.
Appliance connected to power at the first time
When the appliance is connected to power at the first time, the
display will be lit for 2 seconds beforegoing normal and the appliance
runs with intelligence function.
Display control
When the refrigerator door is closedand there is no button operation
in 3 minutes, the display light goes off.
When the display light is off, open the refrigerator door or click any
button to light it up.
Temperature setting
1) Click the “refrigerator” or “freezer” button and when it flickers
in the symbol, temperatures can be set; each time when the button is
clicked, the temperature changes accordingly (the display shows the
temperature accordingly). Temperatures cannot be set under functions
of fast cooling, fast freezing, intelligence and vacation.
2) Under temperature setting, if there is no button operation in 5 seconds, the button
stops flickering and the set temperature comes into effect.
3)Temperature cycle
Refrigerator: 2
°C→3°C→4°C→5°C→6°C→7°C→8°C→OFF→2°C
Freezer: -24°C→-23°C→-22°C→-21°C→-20°C→-19°C→-18°C→-17°C→-16°C→-24°C
