Remote Controller ESIE11-05
84 Functional Description
(a)
Refer to page 92 where [C-03] is explained.
9 Automatic temperature compensation
00 Leaving water temperature compensation value
(heating)
0 –2~2 0.2 °C
01 Leaving water thermistor auto corrective function 1 (ON) 0/1 1 —
02 Not applicable. Do not change the default value. 0 — — —
03 Leaving water temperature compensation value
(cooling)
0 –2~2 0.2 °C
04 Not applicable. Do not change the default value. 0 — — —
A Option setup
00 Not applicable. Do not change the default value. 0 — — —
01 Not applicable. Do not change the default value. 0 — — —
02 Not applicable. Do not change the default value. 5 — — —
03 Allowable overshoot on leaving water 3 1~5 0.5 °C
04 Ethylene glycol concentration 00~11—
b Settings are not applicable
00 Not applicable. Do not change the default value. 35 — — —
01 Not applicable. Do not change the default value. 45 — — —
02 Not applicable. Do not change the default value. 1 — — —
03 Not applicable. Do not change the default value. 70 — — —
04 Not applicable. Do not change the default value. 70 — — —
C Leaving water temperature limits
00 Set point: heating leaving water maximum
temperature
50 37~50 1 °C
01 Set point: heating leaving water minimum
temperature
25 25~37 1 °C
02 Set point: cooling leaving water maximum
temperature
20 18~22 1 °C
03 Set point: cooling leaving water minimum
temperature
5
Q
(a)
~18
1°C
04 Not applicable. Do not change the default value. 0 — — —
d Settings are not applicable
00 Not applicable. Do not change the default value. 10 — — —
01 Not applicable. Do not change the default value. 30 — — —
02 Not applicable. Do not change the default value. 15 — — —
03 Not applicable. Do not change the default value. 15 — — —
04 Not applicable. Do not change the default value. 40 — — —
E Service mode
00 Not applicable. Do not change the default value. 0 — — —
01 Not applicable. Do not change the default value. 0 — — —
02 Not applicable. Do not change the default value. 0 — — —
03 Not applicable. Do not change the default value. 1 — — —
04 Pump only operation 00~251—
F Settings are not applicable
00 Not applicable. Do not change the default value. 5 — — —
01 Not applicable. Do not change the default value. 0 — — —
02 Not applicable. Do not change the default value. 1 — — —
03 Not applicable. Do not change the default value. 10 — — —
04 Not applicable. Do not change the default value. 50 — — —
First
code
Second
code
Setting name
Installer setting at variance with default value
Default
value
Range Step UnitDate Value Date Value
