Gigabyte G25N-G51 (rev. 400) [12/136] 2 product specifications
![Gigabyte G25N-G51 (rev. 400) [12/136] 2 product specifications](/views2/1681161/page12/bgc.png)
- 12 - Hardware Installation
1-2 Product Specications
Motherboard w MG50-G20
CPU w Support for Intel
®
Xeon
®
E5-2600 V3/V4 series processors in the LGA2011
package
w L3 cache varies with CPU
w Supports Dual QuickPath Interconnect up to 9.6GT/s
w Enhanced Intel SpeedStep Technology (EIST)
w Support Intel Virtualization Technology (VT)
Chipset w Intel
®
C612 (Wellsburg) Chipset
Memory w 24 x DIMM slots
w DDR4 memory supported only
w Quad channel memory architecture
w ECC RDIMM / LRDIMM modules supported
w Single and dual rank RDIMM modules up to 32GB supported
w 3DS LRDIMM modules up to 128GB supported
w 1.2V modules: 1600/1866/2133/2400 MHz
LAN w Intel
®
82599ES supports dual 10G SFP+ ethernet LAN ports
w 1 x Server Management GbE LAN port
Expansion Slot w 8 x PCIe x16 (Gen3 x16 bus) connectors supporting:
w Intel
®
Xeon Phi cards
w NVIDIA
®
cards
w AMD
®
cards
w Please contact us for details about the supported card models
w 1 x Half-length low-prole slot
w 1 x PCIe x16 (Gen3 x8 bus) connector
w 1 x Proprietary PCIe x8 (Gen3 x8 bus) mezzanine connector
Onboard
Graphics
w ASPEED
®
AST2400 supports 16MB DDR3 VRAM
Mass Storage w 2 x 2.5" hot-swappable NVMe bays
w 6 x 2.5" hot-swappable HDD/SSD bays
w Support for Intel IRSTe SATA RAID 0, RAID 1, RAID 5, RAID 10
System Fans w 8 x 80x80x38mm 15000rpm
USB w Up to 4 USB 3.0 ports (2 on the back panel, 2 additional ports via the USB
brackets connected to the internal USB headers)
