Gigabyte G25N-G51 (rev. 400) [7/136] Box contents

- 7 -

Box Contents

G25N-G51 System

Heat Sink x 2

Rail kits x 1

• The box contents above are for reference only and the actual items shall depend on the product package you obtain.

The box contents are subject to change without notice.

• The motherboard image is for reference only.
