- 13 - GSM Server
2-5-2 Installation/Uninstallation Steps for CentOS 7, RHEL, Fedora
(Login as root)
1. Before installation, please check the packages sudo and firewalld are already installed.
Otherwise, GSM Server installation will fail.
#yuminstallsudorewalld
2. Use RPM package to install GSM Server.
# rpm -ivh gsm-x.x-1.x86_64.rpm
3. Installer will patch PostgreSQL which does not install yet and ask user to set password for
PostgreSQL.
4. Makesurethepackage‘fontcong’isalreadyinstalledbeforestartingGSMServer.
Installthepackage:‘fontcong’.
#yuminstallfontcong
5. Finish and start up the GSM Server web page
Connect to GSM Server: http://{your IP address}:8080/GSM
6. Uninstall GSM Server
#rpm –e gsm-x.x-1.x86_64
NOTE!
1. Installation will detect PostgreSQL 9.2 and modify its
conguration. Please backup PostgreSQL settings before
you install GSM Server. However, if PostgreSQL 9.2
doesn’t exist, do not install any PostgreSQL and skip this
suggestion, please.
2. Installation will install and place Java and PostgreSQL
sources for GSM Server to /opt. Do not modify and
remove them. It’s very important.
3. After finishing installation, installer adds firewall
exception, such as 8080, 8443, 162, 69 and tftp, to public
zone. If you do not use public zone as default, please add
rewall exception manually.
