3-7-1 IP Range

User can specify the IP range that is scanned during a normal discovery run. Follow the steps

outlinedbelowtocongureIPdiscover.

1. Select Connection Interface to search BMC Server.

2. Click Create row to specify the IP range in the respective columns.

3. Enter Start IP and End IP in the respective columns.

4. Select Scan Type anddenethe Policy Name.

5. Whenyounishtheconguration,clickSubmittosaveyourconguration.

Scan Type Description

BMC Baseboard management controller, which gives a user or

administrator the ability to control a remote system and

the ability to perform a variety of functions. With BMC,

data is only transmitted within the local area network.

CMC Chassis Management Controller, which provides

functionality for managing multiple server nodes within a

single chassis, or multiple chassis. CMC is a higher level

of control and monitoring of one or multiple chassis.

RMC Rack Management Controller. Similar with BMC, CMC

provides LAN-based system console access as well as

remote system management functions. RMC provides

out-of-the-band functions and giving you complete access

to your server from any location via a web browser.
