ELECTRICAL SPECIFICATIONS
37/62
EWAT~B-XS/L
MODEL
EWAT320B-
XS(L)A2
EWAT360B-
XS(L)A1
EWAT430B-
XS(L)A2
EWAT470B-
XS(L)A2
EWAT540B-
XS(L)A2
POWER SUPPLY
Phases
No.
3
3
3
3
3
3
Frequency
Hz
50
50
50
50
50
50
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
10%
10%
10%
UNIT
Maximum inrush current
A
570
565
575
638
643
717
Nominal running current
cooling
A
184
193
209
235
260
299
Maximum running current
A
260
258
268
335
343
420
Maximum current for wires
sizing
A
286
284
295
369
378
462
FANS
Nominal running current
cooling
A
20
23
23
26
30
33
COMPRESSORS
Phases
No.
3
3
3
3
3
3
Voltage
V
400
400
400
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
10%
10%
10%
Maximum running current
A
240
235
245
309
314
387
Starting method
DOL
DOL
DOL
DOL
DOL
DOL
MODEL
EWAT600B-
XS(L)A2
EWAT660B-
XS(L)A2
POWER SUPPLY
Phases
No.
3
3
3
Frequency
Hz
50
50
50
Voltage
V
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
UNIT
Maximum inrush current
A
791
795
800
Nominal running current
cooling
A
335
361
388
Maximum running current
A
501
509
517
Maximum current for wires
sizing
A
551
559
568
FANS
Nominal running current
cooling
A
40
43
46
COMPRESSORS
Phases
No.
3
3
3
Voltage
V
400
400
400
Voltage tolerance Minimum
%
-10%
-10%
-10%
Voltage tolerance Maximum
%
10%
10%
10%
Maximum running current
A
461
466
470
Starting method
DOL
DOL
DOL
Fluid: Water
Allowed voltage tolerance ± 10%. Voltage unbalance between phases must be within ± 3%.
Maximum starting current: In case of inverter driven units, no inrush current at start up is experienced.
Nominal current in cooling mode is referred to the following conditions: evaporator 12/7°C; ambient 35°C; compressors + fans current.
Maximum running current is based on max compressor absorbed current in its envelope and max fans absorbed current
Maximum unit current for wires sizing is based on minimum allowed voltage
Maximum current for wires sizing: (compressors full load ampere + fans current) x 1,1.
The data are referred to the standard unit without options.
For the electrical data of the hydronic kit refer to "Options technical data"
All data are subject to change without notice. Please refer to unit nameplate data.
