MEAN WELL SP-750-5 [29/32] Selection guide
![MEAN WELL PM-20-15 [29/32] Selection guide](/views2/1677224/page29/bg1d.png)
Type Picture Model
Input Voltage
(VAC)
Output Voltage
(VDC)
Dimension
(LxWxH) (mm)
Insulation
Interchangeable
GEM06I
80~264
5 , 6, 7.5 , 9 , 12 , 15 , 18 , 24
73.9 x 39 x 48.5
GEM12I 5 , 7.5 , 9 , 12 , 15 , 18 , 24 , 48
GEM18I 5 , 9 , 12 , 15 , 18 , 24 , 48
75.5 x 39.1 x 56.2
GEM30I 5 , 7.5, 9 , 12 , 15 , 18 , 24 , 48
GEM40I 5 , 9 , 12 , 15 , 18 , 24 , 48
GEM60I 5 , 7.5, 9 , 12 , 15 , 18 , 24 , 48
Wall-mounted
GSM06U/E
80~264
5 , 6 , 7.5 , 9 , 12 , 15 , 18 , 24 66 x 32 x 42.5
GSM12U/E
5 , 7.5 , 9 , 12 , 15 , 18 , 24 , 48
62.2 x 27.4 x 45.5
GSM18U/E
79 x 54 x 33 GSM25U/E
GSM36U/E
GSM60U/E
75.5x 32x 47.5
Desktop
GSM18B
80~264
5 , 7.5 , 9 , 12 , 15 , 18 , 24 , 48
79 x 54 x 33
A Type:
B Type:
GSM25B
GSM36B
GSM40A/B
125 x 50 x 31.5
GSM60A/B
GSM90A/B 12 , 15 , 19 , 24 , 48 145 x 60 x 32
GSM120A/B
12 , 15 , 20 , 24 , 48
167 x 67 x 35
GSM160A/B 175 x 72 x 35
GSM220A/B
210 x 85 x 46
Selection Guide
Size Picture Model
Output Power
(W)
Input Voltage
(VAC)
Output Voltage
(VDC)
Dimension
(LxWxH) (mm)
Insulation
Fan Fanless
3”x 2”
RPS-30 - 30
80~264
3.3 , 5 , 7.5 , 12 , 15 , 24 , 48
76.2 x 50.8 x 24
RPS-45 - 45
RPS-65 - 65
RPS-120S
- 120 12 , 15 , 24 , 27 , 48
4”x 2”
RPS-60
- 60
90~264
3.3 , 5 , 12 , 15 , 24 , 48
101.6 x 50.8 x 29
RPD-60 5 / 12 , 5 / 24
RPT-60 3.3 , ±5 , ±12 , ±15 , 24
RPS-120 120 84
80~264
12 , 15 , 24 , 27 , 48
RPS-200
200 140
5”x 3”
RPS-75
100 75
90~264
3.3 , 5 , 12 , 15 , 24 , 36 , 48
127 x 76.2 x 31
RPD-75 5 / 12 , 5 / 24
RPT-75 3.3 , ±5 , ±12 , ±15 , 24
RPS-160 160 110 5 , 12 , 15 , 24 , 48
127 x 76.2 x 34.6
RPT-160 150 100 ±5, ±12, ±15 , 24
RPS-300 300 200 12 , 15 , 24 , 27, 48
127 x 76.2 x 35
RPS-400 400 250
80~264
12 , 15 , 18 , 24 , 27, 36 , 48
RPS-500 500 320 12 , 15 , 18 , 24 , 27, 36 , 48 127 x 76.2 x 40
7”x 4.2” MPQ-200 - 200 90~264 ±5 , ±12 , ±15 , 24 177.8 x 107.2 x 35.5
AC/DC
AC/DC
External Adaptor
Open Frame Type
