Universal AC input / Full range

Built-in active PFC function, PF>0.95

Protections: Short circuit / Overload / Over voltage / Over temperature

Forced air cooling by built-in DC Fan

Output voltage programmable from 20~110% by 1~5.5VDC external

control signal

Built-in remote ON-OFF control

Built-in fan speed control

Fixed switching frequency at 100KHz

3 years warranty

SPECIFICATION

SPV-300-24SPV-300-12 SPV-300-48

MODEL

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

RIPPLE & NOISE (max.) Note.2

OUTPUT VOLTAGE ADJ. RANGE

VOLTAGE TOLERANCE Note.3

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME

HOLD UP TIME (Typ.)

VOLTAGE RANGE

Note.5

FREQUENCY RANGE

POWER FACTOR (Typ.)

EFFICIENCY (Typ.)

INPUT

ENVIRONMENT

INRUSH CURRENT (Typ.)

LEAKAGE CURRENT

REMOTE CONTROL

OUTPUT VOLTAGE TRIM

OVER TEMPERATURE

SAFETY STANDARDS

SAFETY

WITHSTAND VOLTAGE

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSION

OTHERS

NOTE

PACKING

OVERLOAD

OVER VOLTAGE

PROTECTION

24V12V 48V

12.5A25A

6.25A

0 ~ 12.5A0 ~ 25A 0 ~ 6.25A

300W300W 300W

150mVp-p150mVp-p 240mVp-p

20 ~ 26.4V

10.8 ~ 13.2V

41 ~ 52.8V

±1.0%±1.0% ±1.0%

±0.2%±0.3% ±0.2%

±0.5%±0.5% ±0.5%

800ms, 50ms/230VAC 2500ms, 50ms/115VAC at full load

16ms/230VAC 16ms/115VAC at full load

88 ~ 264VAC 124 ~ 370VDC

47 ~ 63Hz

PF>0.95/230VAC PF>0.98/115VAC at full load

85%83.5% 86.5%

57.6 ~ 67.2V

9.6 ~ 52.8V

20A/115VAC 45A/230VAC

<1mA / 240VAC

4 ~ 10VDC power off, <0 ~ 0.8VDC power on

2.4 ~ 13.2V

105 ~ 135% rated output power

27.6 ~ 32.4V

4.8 ~ 26.4V

13.8 ~ 16.2V

Protection type : Constant current limiting, recovers automatically after fault condition is removed

Protection type : Shut down o/p voltage, re-power on to recover

Shut down o/p voltage, recovers automatically after temperature goes down

UL60950-1, TUV EN60950-1 approved

I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

-20 ~ +65 (Refer to "Derating Curve")℃

20 ~ 90% RH non-condensing

-40 ~ +85 , 10 ~ 95% RH non-condensing℃

±℃ ℃0.03%/ (0 ~ 50 )

10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes

207K hrs min. MIL-HDBK-217F (25 )℃

215*115*50mm (L*W*H)

1.1Kg; 12pcs/14Kg/0.92CUFT

■ Features :

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on

a mm* mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives.360 360 For guidance on how to

perform these EMC tests, please refer to EMI testing of component power supplies. (as available on http://www.meanwell.com)

5. Derating may be needed under low input voltages. Please check the derating curve for more details.

SPV-300 series

300W Single Output with PFC Function

FUNCTION

EMC

(Note 4)

ISOLATION RESISTANCE

Compliance to EN55032 (CISPR32) Class B, EN61000-3-2,-3

Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level, criteria A

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃

AC CURRENT (Typ.)

3.6A/115VAC 1.8A/230VAC

EMC IMMUNITY

EMC EMISSION

File Name:SPV-300-SPEC 2017-07-14
