General Outline ESiE04-03
1–14 Part 1 – System Outline
3
11
4
5
1.5 Technical Specifications: EUWA*24KAZW1
Technical
specifications
The table below contains the technical specifications.
Model EUWAN24KAZW1 EUWAP24KAZW1 EUWAB24KAZW1
Nominal cooling
capacity
55.3 kW
Nominal input
24.0 kW 24.0 kW
Capacity steps
0%-50%-100%
Compressor
Type Hermetically sealed scroll
Speed 2900 rpm
Crankcase heater 50 W
No. x model (W1) 2 x JT335DA-YE
Evaporator
Type Brased plate-heat exchanger
No. x model 1 x AC130-58DQ
Min.water volume in
the system
(1)
132 l
Water flow rate Min.: 79 l/min
Max.: 317 l/min
Nominal water flow 158 l/min
Nom. water
pressure drop
22 kPa
Insulation material Climaflex
Condenser
Type Cross fin coil Hi-X tubes and PE coated waffle louvre fins
Rows x stages x fin
pitch
2x50x2mm
Face area 2 x 1.970 m²
Nominal air flow 2 x 170 m³/min
Discharge Vertical
Fan type Direct drive
No. of fans 4
No. of motors x
output
2 x 190 kW + 2 x 230 kW
Piping connections
Evap. water in/outlet FBSP 2”
Refrigerant circuit
Refrigerant type R-407C
Refrigerant charge 2 x 6.0 kg
Refrigerant control Thermostatic expansion valve
Oil type Idemitsu FVC 68D
