Daikin EUWYP10KAZW1 [28/215] 18 part 1 system outline
![Daikin EUWYP10KAZW1 [28/215] 18 part 1 system outline](/views2/1683245/page28/bg1c.png)
General Outline ESiE04-03
1–18 Part 1 – System Outline
3
11
4
5
(1)
: The table below contains the minimum water volume settings.
Oil charge volume 1.5 l 2.7 l
No. of circuits 1
Pump
No. x type __ 1 x Horizontal multi-stage end-suction __ 1 x Horizontal multi-stage end-suction
Model __ CH4-30 __ CH4-30
Nominal static
height pump
__ Cooling: 244 kPa
Heating: 236 kPa
__ Cooling: 219 kPa
Heating: 214 kPa
Nominal static
height unit
__ Cooling: 223 kPa
Heating: 205 kPa
__ Cooling: 171 kPa
Heating: 160 kPa
Hydraulic components
Buffer tank __ 55 l __ 55 l
Unit water volume 2l 3l 59l 3l 3l 59l
Expansion vessel __ 12 l __ 12 l
Pre-pressure
expansion vessel
1.5 bar 1.5 bar
Safety valve __ 3 bar __ 3 bar
Dimensions
(h x w x d)
1230 x 1290 x 734 mm
Weight
Machine weight 163 kg 181 kg 193 kg 227 kg 241 kg 253 kg
Operation weight 165 kg 184 kg 252 kg 230 kg 244 kg 312 kg
Casing
Colour Ivory white / Munsell code 5Y7.5/1 / ± RAL 7044
Material Polyester coated galvanised steel plate
Sound power
level
(2)
67 dBA 76 dBA
Safety devices
■ Low-pressure switch
■ High-pressure switch
■ Pump motor overcurrent
■ Discharge temperature control
■ Outlet water temperature protection
■ Compressor motor overcurrent relay
■ Fan thermal protector
■ Anti-recycling and guard timer
■ Digital display controller with electronic temperature control
■ Reverse phase protector
■ Flow switch.
Model EUWYN5KAZW1 EUWYP5KAZW1 EUWYB5KAZW1 EUWYN8KAZW1 EUWYP8KAZW1 EUWYB8KAZW1
Setting EUWY*5-8KAZW1
The minimum water volume for standard thermostat difference setting 3 K
For reduced setting multiply this water volume by 3/new setting
Minimum allowable setting 0.1 K
