MEAN WELL APV-8E-24 [2/3] Series

SPECIFICATION

MODEL

APV-8E-5

APV-8E-12

APV-8E-24

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

Note.4

FREQUENCY RANGE

EFFICIENCY (Typ.)

AC CURRENT

INPUT

INRUSH CURRENT(Typ.)

LEAKAGE CURRENT

SAFETY STANDARDS

WORKING TEMP.

WORKING HUMIDITY

NOTE

PACKING

OVER LOAD

OVER VOLTAGE

5V

12V

24V

1.4A

0.67A

0.34A

250mVp-p

250mVp-p

300mVp-p

±5.0%

±1.0%

±2.0%

500ms, 30ms / 230VAC

180 ~ 264VAC 254 ~ 370VDC ( )

47 ~ 63Hz

±℃ ℃0.03%/ (0 ~ 45 )

10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. Derating may be needed under low input voltage. Please check the static characteristics for more details.

5. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be

affected by the complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.

6. When applying DC voltage for input, please connect the brown input wire to the positive side whereas blue input wire to the negative side.

Protection type : Shut off o/p voltage, clamping by zener diode

EMC

PROTECTION

20ms/230VAC at full load

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

I/P-O/P:3.75KVAC

I/P-O/P:>100M Ohms / 500VDC / 25 / 70% RH℃

EMC IMMUNITY

Compliance to EN55015,EN61000-3-2 Class A,EN61000-3-3

SHORT CIRCUIT

Hiccup mode, recovers automatically after fault condition is removed

POWER FACTOR (Typ.)

PF>0.5/230VAC at full load
