D–EIMAC01502–18_02EN - 19/23
Table 3 –Routine Maintenance Plan for Critical Application and/or Highly Aggressive Environment
List of Activities (Note 8)
Weekly
Monthly
(Note 1)
Yearly/Seas
Onal (Note
2)
General:
Reading of operating data (Note 3)
X
Visual inspection of unit for any damage and/or loosening
X
Verification of thermal insulation integrity
X
Clean
X
Paint where necessary
X
Clean and paint where necessary
X
Analysis of water (6)
X
Check of flow switch operation
X
Electrical:
Verification of control sequence
X
Verify contactor wear – Replace if necessary
X
Verify that all electrical terminals are tight – Tighten if necessary
X
Clean inside the electrical control board
X
Visual inspection of components for any signs of overheating
X
Verify operation of compressor and oil heater
X
Measure compressor motor insulation using the Megger
X
Clean air intake filters of the electrical panel
X
Verify operation of all ventilation fans in the electrical panel
X
Refrigeration circuit:
Check for any refrigerant leakage
X
Verify refrigerant flow using the liquid sight glass – Sight glass full
X
Verify filter dryer pressure drop
X
Verify oil filter pressure drop (Note 5)
X
Analyse compressor vibrations
X
Analyse compressor oil acidity (7)
X
Condenser section:
Clean water rinse condenser coils (Note 4)
X
Quarterly clean condenser coils (E-coated only)
X
Verify that fans are well tightened
X
Verify condenser coil fins – Comb if necessary
X
Check the aspect of the plastic protection of the copper/aluminum
connection
X
Notes:
8. Units placed or stored in a Highly Aggressive Environment for long time without operation are still subject to those routine maintenance steps.
8.2 Unit Maintenance and Cleaning
Unit exposed to a highly aggressive environment can face corrosion in a shorter time than ones installed on a standard
environment. Corrosion causes a rapid rusting of the frame core, consequently decreases unit structure life time. To avoid
that, it is necessary to wash periodically the frame surfaces with water and suitable detergents.
In case of part of unit frame paint came off, it is important to stop its progressive deterioration by repainting the exposed
parts using proper products. Please contact factory to get the required products specifications.
8.3
Note: in case of just salt deposits are present, it is enough to rinse the parts with fresh water.
8.4 Microchannel Coil Maintenance
Routine cleaning of coil surfaces is essential to maintain proper operation of the unit, avoid corrosion and rusting.
Elimination of contamination and removal of harmful residues will greatly increase the life of the coil and extend the life of
the unit.
Relative to fin and tube heat exchangers, microchannel coils tend to accumulate more of the dirt on the surface and of the
less dirt inside which can make them easier to clean.
The following maintenance and cleaning procedure are recommended as part of the routine maintenance activities.
1. Remove surface dirt, leaves, fibers, etc. with a vacuum cleaner (preferably with a brush or other soft attachment rather
than a metal tube), compressed air blown from the inside out, and/or a soft bristle (not wire!) brush. Do not impact or
scrape the coil with the vacuum tube, air nozzle, etc..
