ELG-150 series
84~150W Constant Voltage + Constant Current LED Driver
INSTALLATION MANUAL
AC/L(Brown)
AC/N(Blue)
※ 3Y Model (3-wire input)
PE (Green/Yellow)
tc
: Max. Case Temperature
tc
208
219
195
300±20
45.8
63
105
20
4- 4.5ψ
SJOW 17AWGx3C
&H05RN-F 1.0mm
2
SJOW 17AWGx2C
&05RN-F 1.0mm
2
◎ Note1: Please connect the case to PE for the complete EMC deliverance and safety use.
◎ Note2: Please contact MEAN WELL for input wiring option with PE.
File Name:ELG-150-SPEC 2018-09-30
208
219
195
200±20
300±20
45.8
63
35.5
35
105
20
DIM-(Black)
DIM+( )Gray
AUX-(White)
AUX+( )Red
4- 4.5ψ
※ BE-Type
tc
: Max. Case Temperature
tc
SJOW 17AWGx3C
&H05RN-F 1.0mm
2
Vo+(Red)
Vo-(Black)
SJOW 17AWGx2C
&05RN-F 1.0mm
2
SJOW 17AWGx4C
&H05RN-F 1.0mm
2
AC/L(Brown)
AC/N(Blue)
FG (Green/Yellow)
300±20
