1.2 Specications
Platform
•
ATX Form Factor
•
2oz Copper PCB
CPU
•
Supports 10
th
Gen and future generation Intel® Core
TM
Processors (Socket 1200)
•
Digi Power design
•
15 Power Phase design
•
Supports Intel® Turbo Boost Max 3.0 Technology
•
Supports Intel® K-Series unlocked CPUs
•
Supports ASRock BCLK Full-range Overclocking
•
Supports ASRock Hyper BCLK Engine III
Chipset
•
Intel
®
Z490
Memory
•
Dual Channel DDR4 Memory Technology
•
4 x DDR4 DIMM Slots
•
Supports DDR4 4666+(OC)*/4600/4500/4400/4333/4266
(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/
3600(OC)/3200(OC)/2933/2800/2666/2400/2133 non-ECC,
un-buered memory
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
* Core
TM
(i9/i7) support DDR4 up to 2933; Core
TM
(i5/i3),
Pentium® and Celeron® support DDR4 up to 2666.
•
Supports ECC UDIMM memory modules (operate in non-
ECC mode)
•
Max. capacity of system memory: 128GB
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
•
15μ Gold Contact in DIMM Slots
Expansion
Slot
•
3 x PCI Express 3.0 x16 Slots (PCIE1/PCIE3/PCIE5: single
at x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE3); triple at x8
(PCIE1) / x8 (PCIE3) / x4 (PCIE5))*
* Supports NVMe SSD as boot disks
•
2 x PCI Express 3.0 x1 Slots
