Fatal1ty B360 Gaming K4 Series

2.8 M.2_SSD (NGFF) Module Installation Guide (M2_1

and M2_2)

e M.2, also known as the Next Generation Form Factor (NGFF), is a small size and

versatile card edge connector that aims to replace mPCIe and mSATA. e Ultra M.2

Socket (M2_1) supports SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3

x4 (32 Gb/s). e M.2 Socket (M2_2) supports M Key type 2230/2242/2260/2280 M.2

SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x2 (16 Gb/s)**

* If M2_1 is occupied by a SATA-type M.2 device, SATA_2 will be disabled.

* If M2_2 is occupied by a SATA-type M.2 device, SATA_1 will be disabled.

* If M2_2 is occupied by a PCIE-type M.2 device, SATA_0 will be disabled.

Installing the M.2_SSD (NGFF) Module

e following is an example of installing M.2_SSD (NGFF) module into the M2_1.

Step 1

Prepare a M.2_SSD (NGFF) module

and the screw.

BCDE

Step 2

Depending on the PCB type and

length of your M.2_SSD (NGFF)

module, nd the corresponding nut

location to be used.

No. 1 2 3 4 5

Nut Location A B C D E

PCB Length 3cm 4.2cm 6cm 8cm 11cm

Module Type Type2230 Type 2242 Type2260 Type 2280 Type 22110
