MEAN WELL ELG-300-12A [2/6] Elg 300

SPECIFICATION

MODEL

OUTPUT

VOLTAGE RANGE Note.5

FREQUENCY RANGE

POWER FACTOR

EFFICIENCY (Typ.)

AC CURRENT

INPUT

INRUSH CURRENT(Typ.)

LEAKAGE CURRENT

EMC IMMUNITY

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSION

OTHERS

NOTE

PACKING

OVER TEMPERATURE

OVER VOLTAGE

500ms, 100ms/230VAC, 500ms, 100ms/115VAC

10ms/ 230VAC 10ms/ 115VAC

47 ~ 63Hz

3A / 115VAC 1.6A / 230VAC 1.3A/277VAC

<0.75mA / 277VAC

Compliance to

EN55015

,EN61000-3-2 Class C (@load≧50%) ; EN61000-3-3;KN15

20 ~ 95% RH non-condensing

-40 ~ +80℃, 10 ~ 95% RH

±0.03%/℃ (0 ~ 60℃)

10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

ENVIRONMENT

EMC EMISSION

SAFETY &

EMC

PROTECTION

Shut down output voltage, re-power on to recover

SHORT CIRCUIT

I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

TOTAL HARMONIC DISTORTION

DC VOLTAGE

RATED

CURRENT

RATED POWER

VOLTAGE ADJ. RANGE

CURRENT ADJ. RANGE

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME Note.6

HOLD UP TIME (Typ.)

RIPPLE & NOISE (max.) Note.3

VOLTAGE TOLERANCE Note.4

CONSTANT CURRENT REGION Note.2

OVER CURRENT

COLD START 45A(twidth=1200 s measured at 50% Ipeak) at 230VACμ ; Per NEMA 410

MAX. No. of PSUs on 16A

CIRCUIT BREAKER

2 units (circuit breaker of type B) / 4 units (circuit breaker of type C) at 230VAC

MAX. CASE TEMP.

Tcase=+85℃

Compliance to EN61000-4-2,3,4,5,6,8,11; EN61547, light industry level (surge immunity Line-Earth 6KV, Line-Line 4KV),KN61547

(Please refer to "STATIC CHARACTERISTIC" section)

100 ~ 305VAC 142 ~ 431VDC

   ℃







   







 ℃ 



℃℃









95 ~ 108%

Constant current limiting, recovers automatically after fault condition is removed

PF≧0.95/115VAC, PF≧0.93/230VAC, PF≧0.90/277VAC@full load

THD< 10%(@load≧50%/115VC,230VAC; @load≧75%/277VAC)

Tcase=-40 ~ +85℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)

ELG-300-12A

12V

22A

150mVp-p

10~ 12V

264W

11.2 ~12.8V

11 ~ 22A

±3.0%

±0.5%

±2.0%

91%

13.5 ~ 17V

609K hrs min. Telcordia SR-332 (Bellcore) ; 191Khrs min. MIL-HDBK-217F (25℃)

246*77*39.5mm (L*W*H)

1.45 Kg; 9pcs /13.5Kg / 0.76CUFT

224.4W

200VAC ~ 305VAC

100VAC ~ 180VAC

File Name:ELG-300-SPEC 2019-06-21

SAFETY STANDARDS

UL8750(type”HL”)(Except for 12V), CSA C22.2 No. 250.13-12; ENEC EN61347-1, EN61347-2-13 independent, EN62384;

EAC TP TC 004; GB19510.1,GB19510.14; KC61347-1,KC61347-2-13; IP67 approved

200VAC ~ 305VAC

100VAC ~ 180VAC

18.7A

300W Constant Voltage + Constant Current LED Driver

ELG-300

ELG-300-24A

24V

12.5A

240mVp-p

14.4~ 24V

300W

22.4 ~25.6V

6.25 ~ 12.5A

±2.0%

±0.5%

±1.0%

255W

10.63A

94%

27 ~ 34V
