File Name:ELG-300-SPEC 2019-06-21
MECHANICAL SPECIFICATION
CASE NO.: 266A Unit:mm
Vo+(Red)
Vo-(Black)
SJOW 17AWGx3C
SJOW 14AWGx2C
2
&H05RN-F 3×1.0mm
AC/L(Brown)
AC/N(Blue)
PE (Green/Yellow)
36
tc
86
‧ : Max. Case Temperature
tc
300±20
300±20
235
246
222
53.8
77
39.5
4-Φ4.5
INSTALLATION MANUAL
46.5
14
15.8
300W Constant Voltage + Constant Current LED Driver
ELG-300
