XLG-75 XLG-100 XLG-150
AB
XLG
-
100
39
AC input voltage range 100~305VAC ; 142~431VDC
AC inrush current (max.) Cold start, 50A at 230VAC
Over current protection
(for 12,24V)
95%~ 108% Constant current limiting, recovers automatically after fault condition is removed
Over power protection
(for L,M,H-Type)
110% ~ 150% Hiccup mode,
recovers automatically after fault
condition is removed
105% ~ 150% Hiccup mode,
recovers automatically after fault
condition is removed
105% ~ 130% Hiccup mode,
recovers automatically after fault
condition is removed
Over temp. protection
Shut down output voltage, re-
power on to recover
Shutdown output voltage, recovers automatically after fault condition
is removed
Input over voltage
(
for India version)
320~370VAC (Shut down output
voltage when the input voltage
exceeds protection voltage)
320~390VAC (Shut down output voltage when the input voltage
exceeds protection voltage)
Set up time 500ms/230VAC, 1200ms/115VAC
Withstand voltage I/P-O/P:4.2KVAC I/P-FG:2.1KVAC O/P-FG:1.5KVAC
Working temperature Tcase= -40~+90
O
C
Safety standards
UL8750(type"HL"),
UL879(For 12V, 24V), CSA C22.2 No. 250.13-12; ENEC EN61347-1, EN61347-2-13
independent, EN62384; GB19510.1,GB19510.14; IP67 approved，EAC TP TC 004;
EMC standards
EN55015,EN61000-3-2 Class C (@load͘50%) ; EN61000-3-3;EN61000-4-2,3,4,5,6,8,11; EN61547, (surge
immunity Line-Earth 6KV, Line-Line 4KV)(10K/6K option)
Connection
Input SJOW 17AWGx3C & H05RN-F 1.0mm
2
(30cm)
Output
Blank/A-Type: SJOW 17AWGx2C &
H05RN-F 2x1.0mm
2
(30cm)
AB-Type: SJOW 17AWGx2C &
H05RN-F 2x1.0mm
2
(30cm)+UL2517
20AWGx2C(35cm)
Blank/A-Type: SJOW 17AWG/14AWG(for XLG-100-12 and XLG-150-12/24V)
x2C & H05RN-F 2x1.0mm
2
(30cm)
AB-Type: SJOW 17AWGx2C & H05RN-F 2x1.0mm
2
(30cm)+UL2517
20AWGx2C(35cm)
Dimension (LxWxH) (mm) 140x 63x 32 180x 63x 35.5
Features
• Full power output at 70~100% Constant power mode operation
• Wide input range 100~305V AC( Class˺)
• Built-in active PFC function,Class 2 power unit
• Metal case with IP67, suitable for outdoor application
• Surge protection with 6K V/4K V (10K V/6K V optional)
• India (EESL) version with Input Over Voltage Protection can
survive input voltage stress of 440Vac for 48 hours
• 5 years warranty
• Multiple models for choice:
Blank-Type: Io and Vo fixed.
(For harsh environment)
A-Type: IP67 rated.Io adjustable via built-in potentiometer
AB-Type: IP67 rated. Io adjustable through built-in
potentiometer & 3 in 1 dimming function
• Protections：
Over current(for 12,24V)/Over power(for L,M,H-
Type)/Over temperature /Short circuit /Input
over voltage(for India version)
XLG-75 Series XLG-150 Series
XLG-100 Series
Model No. Output I
0
Ripple Effi.
XLG-75 -12 8.4~12V, 5A --- 89%
XLG-75 -24 16.8~24V, 3.1A --- 90%
XLG-75 -L 53~107V, 350~1050mA 3% 91%
XLG-75 -H 27~56V, 650~2100mA 3% 90%
Model No. Output I
0
Ripple Effi.
XLG-150 -12
8.4~12V, 6.5~ 12.5A --- 91.5%
XLG-150
-24
16.8~24V, 3.2~ 6.25A --- 93%
XLG-150
-L
120~214V, 350~1050mA 3% 93%
XLG-150
-M
60~107V, 700~2100mA 3% 92.5%
XLG-150
-H
27~56V, 1400~4170mA 4% 92%
Model No. Output I
0
Ripple Effi.
XLG-100 -12
8.4~12V, 4 ~ 8A --- 92%
XLG-100
-24
16.8~24V,
2 ~ 4A --- 92%
XLG-100
-L
71~142V, 350~1050mA 3% 92.5%
XLG-100
-H
27~56V, 875~2780mA 3% 91%
se
ri
es
75
~
~
150
W
Type HL
Note.1
Type HL
Note.1
Note.1 Note.1
Note.1
Note.1 Note.1
Note.1
Note.1 Note.1
Note.1
Type HL
Note.1
P S
E
= Blank, I; Blank: For standard version, I:For India only
= A, AB, Blank
Note 1:Products sourced from the Americas regions may not have the PSE/
CCC/BIS/KC logo. Please contact your MEAN WELL sales for more information.
P S
E
P S
E
Blank/A
XL
G
-75
0
5VA
C
; 14
2
~4
3
1VD
C
A
