DC/DC LED
Dr
Dr
iv
iv
i
iv
i
er
r
78
Model No.
Input
(VDC)
Output
Io Tol. Effi. Dimming
Voltage
(VDC)
Current
(mA)
LDH-45A-350
9~18
12~86 350 ±5% 91%
Blank&W:
PWM+Analog
LDH-45A-500
9~18
12~86 500 ±5% 90%
LDH-45A-700
9~18
12~64 700 ±5% 90%
LDH-45A-1050
9~18
12~43
1050 ±5% 91%
LDH-45B-350
18~32
21~126
350 ±5% 93%
Blank&W:
PWM+Analog
LDH-45B-500
18~32
21~86 500 ±5% 94%
LDH-45B-700
18~32
21~64 700 ±5% 95%
LDH-45B-1050
18~32
21~43
1050 ±5% 95%
=Blank, W; Blank: pin style, PWM+analog dimming; W: Wire style, PWM+analog dimming
Model No.
Input
(VDC)
Output
Io Tol. Effi. Dimming
Voltage
(VDC)
Current
(mA)
LDH-25-250
9~32
12~84 250 ±5% 89%
0~10V
PWM
LDH-25-350
9~32
12~72 350 ±5% 90%
LDH-25-500
9~32
12~50 500 ±5% 90%
LDH-25-700
9~32
12~36
700 ±5% 90%
=Blank, W; Blank: pin style, PWM+analog dimming; W: Wire style, PWM+analog dimming
Model No.
Input
(VDC)
Output
Io Tol. Effi. Dimming
Voltage
(VDC)
Current
(mA)
LDH-45A-350 DA
9~18 24~86 350 ±5% 91%
DALI
LDH-45A-500
DA
9~18 24~86 500 ±5% 90%
LDH-45A-700
DA
9~18 24~64 700 ±5% 90%
LDH-45A-1050
DA
9~18 24~43 1050 ±5% 91%
LDH-45B-350
DA
18~32 36~126 350 ±5% 93%
DALI
LDH-45B-500
DA
18~32 36~86 500 ±5% 94%
LDH-45B-700
DA
18~32 36~64 700 ±5% 95%
LDH-45B-1050
DA
18~32 36~43 1050 ±5% 95%
=Blank, W; Blank: pin style, DALI dimming; W: Wire style, DALI dimming
Features
• Constant current step-up mode
• Wide input and output voltage range
• High efficiency up to 95%
• Comply with EN55015 without additional
input filter and capacitors
LDH-45
LDH-45DA
LDH-25
• DALI dimming function for DA and WDA type(LDH-45)
• Fully enclosed plastic case (UL 94V-0)
• Economic, high reliability
• Protections: Short circuit / Over voltage / Under voltage
• 3 years warranty
Output current accuracy (Typ.) ±5% at 12VDC or 24VDC input
±5% at 12VDC input for A type; ±5% at
24VDC input for B type
Analog/PWM
dimming &
ON/OFF
control
Remote ON/OFF
Leave open if not used
• Power ON with dimming: PWM DIM~DIM- >
0~10VDC or open circuit
• Power OFF: PWM DIM ~ DIM- < 0.5VDC or short
• Power ON with dimming: PWM DIM~DIM- >
2~8VDC or open circuit
• Power OFF: PWM DIM ~ DIM- < 0.5VDC or short
PWM frequency 1K~10KHz 1KHz-3KHz 10V PWM signal or 0-10V DC input
Short circuit protection Power OFF and fuse open
Over voltage protection >115% rated output voltage
Working temperature
-40~+70
o
C
Safety standards EAC TP TC 004 approved
EMC standards EN55015, EN61547, EN61000-4-2,3,4,6,8, EAC TP TC 020
Dimension (LxWxH)(mm) 52.4x 27.2x 24 75x 53x 22.7
LDH-45A/B Series
LDH-25A/B Series
LDH-45A/B-DA Series
Under
Development
U
nder
Development
