ASRock J4105M [15/53] Installing memory modules dimm
![ASRock J4105M [15/53] Installing memory modules dimm](/views2/1688380/page15/bgf.png)
10
English
2.1 Installing Memory Modules (DIMM)
This motherboard provides two 288-pin DDR4 (Double Data Rate 4) DIMM slots, and
supports Dual Channel Memory Technology.
Supported DDR4 Non ECC DIMM
Raw Card
A (1Rx8)
B (2Rx8)
C (1Rx16)
Dual Channel Memory Conguration
DDR4_A1
Populated
DDR4_A2
Populated
1. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4
slot; otherwise, this motherboard and DIMM may be damaged.
2. e DIMM only ts in one correct orientation. It will cause permanent damage to
the motherboard and the DIMM if you force the DIMM into the slot at incorrect
orientation.
